商品編號: Carlisle-BMS13-58

Carlisle- Boeing Specification BMS 13-58 defines SWAMP wire construction 260°C, 600V 鍍鎳銀鐵氟龍耐高溫防濕氣電線(波音公司規範BMS13-58定義)

BMS 13-58

SWAMP is the acronym for Severe Weather and Moisture Prone. Boeing Specification BMS 13-58 defines SWAMP wire construction.

SWAMP Wire applications include:

Test	Requirements
Wire Rating	260°C, 600V
Arc Resistance (Wet & Dry)	67 wires must pass
Dynamic Cut Through	50 lbs. min.
Wicking	1/4" max. distance
Wire-to-Wire Abrasion	7.5 million cycles
Wire Separation	Must pass dry dielectric after test
