Overall Foil/Braid Shield
Low-Capacitance Computer Cables for EIA RS-485 Applications
Plenum-Rated and Non-Plenum

24 AWG Stranded (7x32) TC Conductors • Overall Beldfoil® (100% Coverage) + TC Braid Shield (90% Coverage) • 24 AWG Stranded TC Drain Wire
Polyethylene Insulation • Chrome PVC Jacket
UL AWM Style 2919 (30V 80°C) CM DMX 512

Belden-9841  1P
Belden-9842  2P
Belden-9843  3P
Belden-9844  4P

Plenum • Foam FEP Insulation • Natural Flamarrest® Jacket
300V RMS CMP FT6

Belden-82841  1P
Belden-82842  2P

Plenum • Foam FEP Insulation • Red FEP Jacket
300V RMS CMP FT6

Belden-89841  1P
Belden-89842  2P
DCR = DC Resistance • TC = Tinned Copper
*Capacitance between conductors.
**Capacitance between one conductor and other conductors connected to shield.

Introduction

Belden® paired cable products are manufactured in a variety of gage
sizes, dimensions, insulation materials, shielding configurations,
and jacketing materials including Plenum and High-Temperature
versions to meet the technical requirements of many different types
of systems.
　

Paired cables allow balanced signal transmission, which results
in lower crosstalk through common mode rejection. Due to the
improved noise immunity of twisted pairs, they generally permit
higher data speeds than multi-conductor cables.
　

As an aid to proper cable selection, both the suggested working
voltages and the maximum temperature ratings are indicated for
each applicable paired cable selection.
　

Most of our paired cables are available from stock. Many of these
are available off the shelf from distributors. If you have a new or
unusual application or you cannot find a paired cable in this catalog
section that meets your technical requirements, contact Technical
Support at 1-800-BELDEN-1.
　

Paired Cables Packaging
Belden’s unique UnReel® cable dispenser is available for many
of the paired cable products listed in this section. The letter “U”
before the specified put-up length denotes UnReel packaging
