Test voltage for 5 mm Ø = 15 kV for 7 mm Ø = 20 kV
Breakdown voltage for 5 mm Ø = min. 25 kV for 7 mm Ø = min. 35 kV
Neon-light-Cable, yellow
Nominal voltage 3,5 kV, 4,0 kV or 7,5 kV
Test voltage 10 kV
Specific volume resistivity min. 1012 Ohm x cm
Minimum bending radius 7,5x cable Ø
Radiation resistance up to 20x106 cJ/kg (up to 20 Mrad)
Cable structure
FZ-LSi, blue
Tinned copper-conductor
Conductor consturction see table below
Core insulation of silicone compound type 2GI1 to DIN VDE 0207 part 20
Glass-fibre braiding
Outer sheath of silicone compound type 2GM1 to DIN VDE 0207 part 21
Sheath colour blue
FZ-LS, red
Tinned copper-conductor, 19x0,25 mm Ø
Core insulation of silicone compound type 2GI1 to DIN VDE 0207 part 20
Sheath colour redbrown
Neon-light-cable, yellow
in adapted to DIN VDE 0250 part 1+5
Tinned copper-conductor, 30x0,25 mm
Core insulation of silicone compound type 2GI1 to DIN VDE 0207 part 20
Sheath colour yellow
Properties
Neon-light-cable, yellow
Halogen-free acc. to DIN VDE 0482 part 267, DIN EN 50267-2-2, IEC 60754-2 (equivalent DIN VDE 0472 part 813)
Behaviour in fire no flame propagation acc. to DIN VDE 0482-332-1-2, DIN EN 60332-1-2,IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B)
No formation of corrosive gases
Low smoke density
Very good weather resistance
Note
AWG sizes are approximate equivalent values. The actual cross-section is in mm².
Application
FZ-LSi, blue This ignition cable is suitable for use at high and extremely alternating ambient temperatures up to +180°C. Applications include engine manufacturing, valve manufacturing and heating technology. As protection against mechanical damages a glass fibre braiding and a silicone sheath covers the core insulation. FZ-LS, red This ignition cable is suitable for use at high and extremely alternating ambient temperatures up to +180°C. Applications include the lamp and lighting industry and cooling and airconditioning technology. Neon-light-cable, yellow This cable is primarily suitable for use at high and extremely alternating ambient temperatures such as in the lamp and lighting industry. Protected installation is required.
