• Special drag chain single cores for high
  mechanical stress, adapted to
  DIN VDE 0285-525-2-31/
  DIN EN 50525-2-31
• Temperature range
  flexing -30°C to +90°C
  fixed installation -40°C to +100°C
• Permissible operating temperature
  at conductor +90°C
• Nominal voltage U₀/U 600/1000 V
• Test voltage 3000 V
• Insulation resistance
  min. 20 MOhm x km
• Minimum bending radius
  KOMPOSPEED^® 600
  flexing installation 5x outer Ø
  fixed installation 3x outer Ø
  KOMPOSPEED^® 600-C
  flexing installation 7,5x outer Ø
  fixed installation 4x outer Ø

KOMPOSPEED^® 600

• Tinned copper, extra fine wire conductors,
  bunch stranded to DIN VDE 0295 cl.6,
  col. 4, BS 6360 cl.6 and IEC 60228 cl.6
• Core insulation of special thermoplastic
  polymer, natural coloured
• Outer sheath of special polyolefin
• Sheath colour black (RAL 9005)

KOMPOSPEED^® 600-C

• Structure as above up to core insulation
• Screen of tinned cu-braid,
  coverage approx. 85%
• Outer sheath of special polyolefin
• Sheath colour black (RAL 9005)

• Very good oil resistant
• Halogen free
• Abrasion resistant
• Resistant to
  Coolants
  Microbes
  UV-radiation
  Weather
  Hydrofluoric acid
  Hydrochloric acid
  Diluted sulfuric acid

• The materials used in manufacture are
  cadmium-free and contain no silicone
  and free from substances harmful to the
  wetting properties of lacquers

• AWG sizes are approximate equivalent
  values. The actual cross-section is in mm².

The special single cores are used for permanent flexible applications in machineries, machine tools, composting appliances and sewage-treatment plants, animal stalls and greenhouses and used for permanent flexible application for movable automated machinery parts and multi-shift operation as well as in open air. These cables are installed for flexible use with free movements without tensile stress or forced movements and suitable for application in drag chains. The selected tinned copper wire conductor and tinned copper wire braid permit the installation in aggressive environments as well as hydrogen sulfide, ammonia and sulfur dioxide.
For applications which go beyond standard solutions (for example for composting appliances or high shelf conveyors with extremely high processing speeds etc.) we recommend for our especially developed enquiry sheet for energy guiding systems. Before installation in cable trays please read the instructions. Further technical details see selection table for drag chain cables, see lead text.
KOMPOSPEED^® 600-C
These screened cables are particularly suitable for the interference-free trans mission in instrumentation and control engineering applications (electromagnetic compatibillity).
EMC = Electromagnetic compatibillity
To optimize the EMC features we recommend a large round contact of the copper braiding on both ends.
CE = The product is conformed with the EC Low-Voltage Directive 2006/95/EC.
