Radiation resistance up to 20x106 cJ/kg (up to 20 Mrad)
Cable structure
Tinned copper-conductor, to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation of cross-linked rubber (SiR) compound type EI2 to DIN VDE 0207-363-1 / DIN EN 50363-1
Core identification to DIN VDE 0293-308
GN-YE conductor, 3 cores and above
Cores stranded in layers with optimal lay-length
Outer sheath of cross-linked rubber compound type EM9 to DIN VDE 0207-363-2-1/DIN EN 50363-2-1
Sheath colour black (RAL 9005) also available in other colours on request
H05SST-F
Constuction as per H05SS-F
Polyester braiding
Properties
Advantages Hardly changes of dielectric strength and the insulation resistance also at high temperatures
These cables may be damaged by pulling over sharp-edges or by abrasion during the installation and application. To avoid this, it should be treated with great care during the installation and application of the cable.
Tests
Behavior in fire Test of vertical flame-propagation to VDE 0482-332-1-2, DIN EN 60332-1-2, not valid for the cables with outer polyesterbraiding (Type H05SST-F)
Note
G = with green-yellow conductor x = without green-yellow conductor
AWG sizes are approximate equivalent values. The actual cross-section is in mm².
Application
Multicore cables insulated and sheathed with heat resistant silicone rubber without strain relieving elements are used in high temperatures or with contact to hot-surfaces. These cables are installed for fixed installation, mechanical protected, for internal wiring of lighting fixtures in industrial application. It is recommended for the application of the apparatus which are moving during the operation with less mechanical stress. CE = The product is conformed with the EC Low-Voltage Directive 2006/95/EC.
