Radiation resistance up to 100x106 cJ/kg (up to 100 Mrad)
Cable structure
Bare copper, extra fine-wire to DIN VDE 0295 cl.6, col. 4, BS 6360 cl.6
Core insulation of PP
Cores stranded in layers with optimally lay-lengths
Core identification to DIN 47100 coloured
Wrapping over the outer layer
Outer sheath of special full-polyurethane compound type TMPU to DIN VDE 0282 Part 10, Annex A and acc. to UL-Std.1581 Tab.50227
Sheath colour grey (RAL 7001)
with meter marking
Properties
The materials used in manufacture are cadmium-free and contain no silicone and free from substances harmful to the wetting properties of lacquers
Tests
PUR outer sheath, flame retardant acc. to DIN VDE 0482-332-1-2, DIN EN 60332-1-2/ IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B)
Low adhesion
High flexibility at low temperatures
High abrasion resistance
Tear and cut-resistant
Notch resistant
Resistant to UV-radiation, Oxygen, Ozone, Hydrolysis, Oil
Partially resistant to Microbial attack, Hydraulic fluids, Coolant emulsion, Alkalis
Note
AWG sizes are approximate equivalent values. The actual cross-section is in mm².
Application
For installation in dry, moist and wet rooms and outdoors with free movement without tensile stress or forced movements, impressively proven in drag chain application. A highly flexible PUR control cable, suitable for frequent and quick lifting and bending stresses in machine engineering and construction, in robot technology and on permanently moving machine components. Long service life guarantees reliable function and high cost-efficiency. For applications which go beyond standard solutions (for example for composting appliances or high shelf conveyors with extremely high processing speeds etc.) we recommend for our especially developed enquiry sheet for energy guiding systems. Before installation in cable trays please read the instructions. Further technical details see selection table for drag chain cables, see lead text. Attractive for export-oriented mechanical engineering. CE = The product is conformed with the EC Low-Voltage Directive 2006/95/EC.
