Bare copper-conductor, to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation of PVC
Core identification see table below
Outer sheath of special PVC
PUR cables
Bare copper-conductor, to DIN VDE 0295 cl.6, extra fine-wire, BS 6360 cl.6, IEC 60228 cl.6
Core insulation of PVC
Core identification see table below
Outer sheath of PUR
Part no. 79907, 75642, 79850
Construction as per SENSORFLEX® two-approvals
Core insulation of polypropylene
Properties
PVC cables
Extensively oil resistant; Chemical Resistance (see table Technical Informations)
PVC self-extinguishing and flame retardant acc. to DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B)
PUR cables
Low adhesion, extremely abrasion resistant, resistant to hydrolysis and microbial attack
Special feature
The cables with the highly flexible stranded conductor cl.6, are suitable for drag chain applications
The types with PVC/PUR sheath material have a PVC inner sheath, with a PUR sheath applied over it by means of coextrusion
Note
AWG sizes are approximate equivalent values. The actual cross-section is in mm².
Application
For decentralised installation and control technology. These cables are used in connector systems for sensors and actuators. In combination with injected circular connectors and installed actuator-sensor boxes, they constitute an important connecting element between the periphery and the PLC in production systems. The assembled cables offer attractive opportunities for reducing costs, not only in the field of automation technology, but also in the entire manufacturing industry. While previously it was necessary to carry out time-consuming wiring of switchgear cabinets and machines, now field bus technology has made it possible to move the periphery interfaces from the switchgear cabinets to the machines and systems. Moving the I/O points to the system periphery enables significant reductions in installation costs. CE = The product is conformed with the EC Low-Voltage Directive 2006/95/EC.
