• PVC power cable, screened to
  UL-Std.1277 TRAY CABLE
• Multinorm
  also conforms to the following standards:
  AWM-Style 2587 to UL-Std.758 (cUL)
  and CSA type TC FT4 to C22.2 no 230, CSA
  C22.2 No 210 I/II A/B 90°C 600 V FT4
• Temperature range
  dry environment
  flexing -5°C to +90°C
  fixed installation -25°C to +90°C
  wet environment
  flexing -5°C to +75°C
  fixed installation -25°C to +75°C
• Nominal voltage UL 600 V
• Test voltage 3000 V
• Breakdown voltage min. 6000 V
• Insulation resistance
  min. 20 MOhm x km
• Minimum bending radius
  10x cable Ø
• Radiation resistance
  up to 80x10⁶ cJ/kg (up to 80 Mrad)
• Coupling resistance
  max. 250 Ohm/km

• Bare copper, fine wire conductors, acc. to
  DIN VDE 0295 cl.5, BS 6360 cl.5 and
  IEC 60228 cl.5
• Core insulation of special PVC class 12 B
  to tab.50.155 acc. to UL-Std.1581
  type TFF acc. to UL-Std.62 (AWG 20-AWG 16)
  type THHW to UL-Std.83 (AWG 14)
• Core identification to DIN VDE 0293
  black cores with continuous white
  numbering
• GN-YE conductor, 3 cores and above
  in the outer layer
• Cores stranded in layers with optimal
  lay-length
• PVC-inner sheath acc. to UL-Std.1277
  tab.11.2
• Tinned copper braided screening,
  approx. 85% coverage
• Outer sheath of special PVC
  acc. to UL-Std.1277 tab.11.2,
• Sheath colour black (RAL 9005)
• with meter marking

• self-extinguishing and flame retardant
  acc. to CSA FT4
• The materials used in manufacture are
  cadmium-free and contain no silicone
  and free from substances harmful to
  the wetting properties of lacquers
• uv-resistant

• G = with green-yellow conductor
  x = without green-yellow conductor (OZ)
• AWG sizes are approximate equivalent
  values. The actual cross-section is in mm².
• unscreened analogue type:
  JZ 604 TC TRAY CABLE

USA NFPA 79 edition 2012 conformant flexible power cables up to 600 V, for all machinery in tool and plant constuction, suitable for installation in dry, humid and damp environments, in the open and in pipes. For underground installation and for open, unprotected installation from the cable rack to machines and industrial plants.
EMC = Electromagnetic compatibillity
To optimize the EMC features we recommend a large round contact of the copper braiding on both ends.
CE = The product is conformed with the EC Low-Voltage Directive 2006/95/EC.
