• Reliable 1000 Base-T performance up to 100 MHz at distances of up to 80m
  • Bend radius of 0.75in (19.0mm), making them extremely flexible and easy to route in tight spaces
  • More durable, smaller in overall size and lighter in weight than comparable cables
  • Applications include in-flight entertainments systems, cabin management systems and ground vehicle bus
  • Meet the flammability requirements of FAR 25.853 and the smoke and toxicity requirements of Boeing and Airbus ABD0031
Pairs  Four (4) twisted pairs
Conductor 26 AWG stranded (19x38) silver-plated copper alloy
  0.0189in/0.48mm diameter
  24 AWG stranded (19x36) silver-plated copper alloy
  0.235in/0.60mm diameter
Insulation Extruded fluoropolymer
  26 AWG: 0.036in/0.91mm diameter
  24 AWG: 0.045in/1.143mm diameter
Binder Skive PTFE tape
Shield Round silver-plated copper braid
  80% minimum coverage
  26 AWG: 0.180in/4.57mm diameter
  24 AWG: 0.230in/5.84mm diameter
Jacket White or Black PTFE
  26 AWG: 0.195in/4.9mm diameter
  24 AWG: 0.245in/6.22mm diameter
Impedance 100 Ohms
DC Resistance 2.76 Ohms/100 ft (24 AWG)
  4.38 Ohms/100 ft (26 AWG)
Vp 70%
Attenuation 26.4 ohms/100 m @ 100 MHz (24 AWG)
  31.6 ohms/100 m @ 100 MHz (26 AWG)
Weight/K ft 35 lbs/1000 ft (24 AWG)
  28 lbs/1000 ft (26 AWG)
Size .245 in (24 AWG)
  .195 in (26 AWG)
Min. Bend Radius 1.00 in (24 AWG)
  0.75 in (26 AWG)
Operating Temperature -55 to 200C
Other ROHS Compliant
  Meets FAR 25.853 and Boeing/Airbus Smoke and Toxicity
