商品編號: A-3JS-0603
EPR/PVC 3C Shielded UL Listed Type MV-105 5 kV 133% and 8 kV 100% 5kV 3C EPR/PVC 高壓隔離電力電纜
For use in power circuits up to 8 kV when installed in open air, conduit, duct or buried directly in the earth, for wet and dry locations. Used for power applications in chemical
plants, refineries, steel mills, industrial plants, utility substations and generating stations.
Power Cable
5 kV Multiconductor - Shielded
EPR/PVC Copper Tape Shield
EPR insulation
PVC jacket
Shielded
UL Listed Type MV-105
SPECIFICATIONS
1. CONDUCTOR: Class B stranded, annealed bare copper
2. CONDUCTOR SHIELD: Conductor is covered with an extruded semiconducting thermoset compound bonded to the insulation
3. INSULATION: Ethylene Propylene Rubber (EPR) with thermoset semiconducting layer and 5 mil copper tape shield
4. ASSEMBLY: The three conductors are cabled with a Class B stranded, uncoated copper grounding conductor and suitable fillers in compliance with UL 1072. A binder tape is
applied overall
5. OVERALL JACKET:Sunlight-resistant black Polyvinyl Chloride (PVC) meeting ICEA and UL requirements
6. STANDARDS: Listed Type MV-105 per UL 1072 and meets the requirements of ICEA S-93-639 and AEIC CS8. Passes UL 1685 70,000 Btu/hr flame test. Sizes 1/0 and larger
marked "for CT use"
7. AMPACITY:Based on three single conductor cables in isolated conduit in air per NEC Table 310.75 with a conductor temperature of 90°C and an ambient temperature of 40°C
8. TEMPERATURE: 105°C
9. VOLTAGE: 5 kV 133% and 8 kV 100%
APPLICATIONS
For use in power circuits up to 8 kV when installed in open air, conduit, duct or buried directly in the earth, for wet and dry locations. Used for power applications in chemical
plants, refineries, steel mills, industrial plants, utility substations and generating stations.
|
