    MGCH - MGCH (EMC) HALOGEN - FREE, FLAME RETARDANT, SCREENED POWER CABLE  無鹵,阻燃,隔離船舶用電力電纜
    看原圖
    30197423




    商品編號: UNTL-MGCH-EMC

    MGCH - MGCH (EMC) HALOGEN - FREE, FLAME RETARDANT, SCREENED POWER CABLE 無鹵,阻燃,隔離船舶用電力電纜



    ★★★★商品說明★★★★

    MGCH - MGCH (EMC)

    HALOGEN - FREE, FLAME RETARDANT, SCREENED POWER CABLE

    CABLE STRUCTURE

    1- CONDUCTOR : Electrolytic, stranded, annealed copper wire. IEC 60228 Class 2 (Class 5 and/or tinned on request).

    2- INSULATION : HF HEPR compound.

    3- BEDDING : Halogen free compound.

    4- SCREEN : Electrolytic copper braided screen (90% coverage). MGCH (EMC) type is wrapped by a copper tape in addition to this screen (100% coverage).

    5- OUTER SHEATH : Halogen-free, flame retardant, thermoplastic polyolefin based compound (HM4 / SHF1) - HD 604. Color: Black or Grey.

    PRODUCTION AND TEST STANDARDS


    CONSTRUCTION : DIN 89158, IEC 60092/353

    TESTS AND MATERIAL : IEC 60092 /350-351-359

    FLAME RETARDATION : IEC 60332 /1, IEC 60332 / 3

    HALOGEN CONTENT : IEC 60754 / 1 - 2

    SMOKE DENSITY : IEC 61034 / 1-2 ( DIN EN 50268/1-2)

    SHIELDING EFFECTIVENES (for EMC type) : DIN EN 50147-1

    WORKING TEMPERATURE : -40°C / + 90°C

    MIN. BENDING RADIUS (FIXED) : 8 x (Overall Diameter)

    RATED VOLTAGE : 0,6 / 1 kV

    TEST VOLTAGE : 3,5 kV

    APPLICATION

    Used as fixed installation cables in various electromechanical and electronic equipments of marine vehicles. Due to its overall screen, environmental electromagnetic interference is minimized.

    ENVIRONMENT

    Usable at all conditions in marine environment such as dry, wet or oily locations.

    SAFETY

    Due to its flame retardant feature, the part which directly contacts with fire will burn but the flame will not spread along the cable length. Thus it prevents the fire from spreading around.
