    M2XY-FR FLAME RETARDANT, XLPE INSULATED, PVC SHEATHED POWER CABLE 阻燃,船舶用電源線
    看原圖
    30197516




      商品編號: UNTL-M2XY-FR

    M2XY-FR FLAME RETARDANT, XLPE INSULATED, PVC SHEATHED POWER CABLE 阻燃,船舶用電源線






    ★★★★商品說明★★★★



    M2XY-FR

    FLAME RETARDANT, XLPE INSULATED, PVC SHEATHED POWER CABLE

    CABLE STRUCTURE
    1- CONDUCTOR : Electrolytic, stranded, annealed copper wire IEC 60228 Class 2 (Class 5 and/or tinned on request).

    2- INSULATION : Crosslinked polyethylen compound (XLPE).

    3- BEDDING : Flame retardant compound.

    4- OUTER SHEATH : Flame retardant and oil resistant PVC based compound (ST2). Color : Dark Grey.

    PRODUCTION AND TEST STANDARDS

    CONSTRUCTION : IEC 60092/353

    TESTS AND MATERIAL : IEC 60092 /350-351-359

    FLAME RETARDATION : IEC 60332 /1, IEC 60332 / 3

    WORKING TEMPERATURE : -20°C / + 90°C

    MIN. BENDING RADIUS (FIXED) : 6 x (Kablo Çap› / Overall Diameter)

    RATED VOLTAGE : 0,6/1 kV

    TEST VOLTAGE : 3,5 kV

    APPLICATION
    Used as fixed installation cables in various electromechanical and electronic equipments, placed deck blow of marine vehicles.

    ENVIRONMENT

    Usable at all conditions in marine environment such as dry, wet or oily locations.

    SAFETY

    Due to its flame retardant feature, the part which directly contacts with fire will burn but the flame will not spread along the cable length. Thus it prevents the fire from spreading around.
