    LAPP-OLFLEX  PLUG H03VV-F Net Connection Cable工業級歐規接頭連接線PVC Net Connection Cable for electrical devices and machines
    看原圖
    5323199


    商品編號: LAPP-OLFLEX-PLUG-H03VV-F

    LAPP, OLFLEX PLUG H03VV-F Net Connection Cable工業級歐規接頭連接線PVC Net Connection Cable for electrical devices and machines

    ÖLFLEX® PLUG H03VV-F Net Connection Cable

    PVC Net Connection Cable for electrical devices and machines

    Approvals of most of the European countries according to the following chart

    Application range

    • Electrical devices
    • Appliances and machinery


    Design

    • First end: injection moulded, angular shock-proof plug with double shock-proof contact
    • 2nd end: straight socket injection moulded
    • Alternatively
    • First end: injection moulded, angular shock-proof plug with double shock-proof contact
    • 2nd end: 30 mm stripped, with conductor end sleeves


    Product features

    • For additional information regarding international plugs, please visit our cable configurator at www.lappkabel.de
    Part number Number of cores and mm² per conductor Outer diameter in mm Länge in m Sheath colour Copper index kg/km
    First end: injection moulded angular shock-proof connector with shock-proof contactSecond end: 30 mm stripped with conductor end sleeves
    70261131 3 G 0,75 5,4 - 6,8 2 black 43.2
    70261132 3 G 0,75 5,4 - 6,8 3 black 64.8
    70261137 3 G 0,75 5,4 - 6,8 2 grey 43.2
    70261138 3 G 0,75 5,4 - 6,8 3 grey 64.8
