    LAPP- ÖLFLEX®  TORSION D FRNC工業級(超柔耐扭曲移動式適風力發電機組)銅網隔離連接線 Screened cold- and oil resistant cables for flexible application under torsional load, halogen free - 0,6/1 kV
    看原圖
    5318541

    商品編號: LAPP-OLFLEX-D-TORSION-FRNC

    LAPP- ÖLFLEX® TORSION D FRNC工業級(超柔耐扭曲移動式適風力發電機組)銅網隔離連接線 Screened cold- and oil resistant cables for flexible application under torsional load, halogen free - 0,6/1 kV

    Screened cold- and oil resistant cables for flexible application under torsional load, halogen free - 0,6/1 kV

     The special construction compensates reliably the permanent torsional movements inside of windmills between the nacelle and the tower; The high flexibility and the good dismantleand stripping properties enable easy space-saving cable installation and fast processing; Saltwater resistant for On- and Off-Shoreapplication; FRNC = Flame Retardant Non Corrosive- Reduction of flame propagation and  density and toxicity of smoke gases   in event of fire- Minimisation of damage to buildings   and production facilities- Safety for maintenance staff resp. in   areas with high personnel concen-  tration; The copper wrapping of the screened Dversion protects against electromagneticinterference

    Application range

    • For fixed, flexible as well as for torsional moved applications in the field of machinery building and wind power plant engineering
    • Especially for the drip loop installation between the rotating nacelle and the stationary windmill tower to connect the generator and control units
    • As torsional moved cable for application in North America with UL WTTC Listing (Wind Turbine Tray Cable) we recommend ÖLFLEX® FORTIS which complies to the NFPA 79 standard resp. UL 2277 and UL 6140 outline
    Part number Number of cores and mm² per conductor Outer diameter in mm Copper index kg/km Weight kg/km
    ÖLFLEX® TORSION D FRNC - screened
    1150111 4 x 2 x 0,5 11,9 71 205
    1150115 12 x 2 x 0,5 18,3 188 518
    1150121 4 x 2 x 0,75 12,7 90 232
    1150125 12 x 2 x 0,75 19,8 258 603
    1150221 18 G 0,75 15,2 180 402
    1150228 50 G 0,75 24,9 470 1079




    ★★★★商品規格描述★★★★


    Design

    • Extra fine wired conductor of plain copper
    • Core insulation of LS0H polyolefin polymer
    • Cores torsion optimized twisted into layers
    • Optional screening (D) of helically tinned copper wire wrapping
    • Outer sheath of halogen free specialcompound, colour black (RAL 9005)

    Approvals (Norm references)

    • UL AWM Style 21288 / cUL AWM II A/B
    • Fire behaviour :- Halogen free (IEC 60754-1)- Corrosivity of gases (IEC 60754-2)- Smoke density (IEC 61034-2)- Flame retardant (IEC 60332-1-2)- No flame propagation (IEC 60332-3-24  resp. IEC 60332-3-25)
    • Oil resistant acc. to EN 60811-2-1and UL OIL RES I and UL OIL RES II
    • UV-resistant according ISO 4892-2
    • Ozone resistant according EN 50396

    Product features

    • Torsion-resistant up to ±150 °/mtr
    • Good weather-, abrasion-, temperature- and UV resistance
    • Resistant against a multitude of oils
    • Halogen free and highly flame retardant
    • Considering economic minimum quantities also customized designs are possible
