YSCT-IP06 DC 5V/12V 網絡攝像機高電功率以太網供電套件 High Power POE Kit (IP06I Injector, IP06S Splitter)

YSCT-IP06

商品型號: IP06

DC 5V/12V 網絡攝像機高電功率以太網供電套件

商品規格:

包含專為支援PoE的網路攝影機及其他支援PoE的網路設備設計的高功率乙太網路供電Injector和Splitter
符合IEEE 802.3at 標準(最大供電功率30W) 可提供電源給網絡電話、無線網路基地台、網路攝影機等
支援10/100/1000M 三種速率傳送
支援PoE電功率最高達30W
電源LED燈號顯示
最遠距離可達100公尺
IP06S PoE splitter 內建風扇可降低工作溫度

產品型號	IP06I	IP06S
電源與網路輸入	RJ45
電源與網路輸出	RJ45	RJ45，DC JACK
RJ45腳位定義	網路：Pins 1，2 、 3，6 、 4，5 、 7，8
RJ45腳位定義	電源：Pins 4，5 、 7，8
最遠傳輸距離	100 公尺
LED 燈號指示	電源：藍色，POE：綠色	電源：藍色 (5V)，紅色 (12V)
PoE 標準	IEEE 802.3at
電源輸出	DC 54V	DC5V：3.6A(Max) DC12V：1.8A (Max)
最大消耗功率	1W	3W
環境規格	工作溫度：0～55℃，儲存溫度：-20～85℃，相對濕度：最高95%
尺寸 mm	117 x 117.7 x 36	117 x 114.2 x 36
重量 g	440	400

Product ID: IP06

High Power POE Kit (IP06I Injector, IP06S Splitter)

Specifications:

This IP06 High Power POE kit is a cost-effective solution to send data and power over original Ethernet network but eliminates the need of power cable and converter. This adds POE functionality to non-POE devices whose power consumption is up to 25W. It is perfect for network application such as IP camera, VoIP and wireless access point This POE kits include two devices, the injector IP06I sends both power and data over signal CAT5 cable to your IP device. The splitter IP06S separates the data and power and delivers them to the IP device.

Features:

Mix Ethernet and power into RJ45 port.
Include IP06I POE injector and IP06S POE splitter.
Complies with IEEE 802.3at Gigabit high power over Ethernet pre-standard,PSE/PD.
IP06I provides DC54V power over RJ45 Ethernet cable to device with Ethernet port.
IP06S splits the DC54V power over RJ45 Ethernet cable into DC 5V/12V output.
Adjustable two different output voltage options (5V/3.6A, 12V/1.8A) to fit various devices.
Supports POE power up to 25 Watts for POE port.
Support 10/100/1000 BASE-T transmission rate.
Power input LED indication.
Distance up to 100 meters (Max)

ITEM NO.	IP06I	IP06S
Power & Data Input	RJ-45
Power & Data Output	RJ-45	RJ45, DC jack
Data Link	Pins 1,2、3,6、4,5、7,8
Power Link	Pins 4,5、7,8
Transmission Range	100 Meters (Max.)
LED Indication	Power: blue, POE: green	Power: blue (5V) red (12V),
POE	IEEE 802.3at Standard
Power Output	DC 54V	DC5V: 3.6A(Max) DC12: 1.8A (Max)
Power Consumption	1W (Max)	3W (Max)
Temperature	Operation: 0 to 55°C, Storage: -20 TO 85°C, Humidity: up to 95%
Dimensions W x H x D mm	117.7 x 117 x 36	113.5 x 117 x 36
Weight g	450 g	400 g
