    HS04 4進1出 HDMI 切換器 4 Input 1 Output HDMI Switcher
    看原圖
    YSCT-HS04

    商品型號: HS04

    4進1出 HDMI 切換器

    商品規格:
    • HS04為HDMI影像切換器
    • 具有4組HDMI輸入及1組HDMI輸出
    • 相容HDMI 1.3a,支援12 Bits Deep Color (傳輸速率最高達 2.25Gbps)
    • 具有自動掃瞄功能 (Auto Scan),在無信號輸入時自動選擇下一個有信號之輸入
    • 具有自動跳臺功能 (Auto Jump),在有新影像輸入時自動選擇到該輸入
    • 可調整 LED 顯示亮度,不會影響或干擾使用投影機時的影片觀看
    • 可由面板按鍵或 IR 紅外線遙控器操作
    • 可加裝RS-232 遠端遙控套件 (選購型號:RC01),由遠端 PC 遙控

    產品型號 HS04
    端子 HDMI Type A
    輸入/輸出 HDMI x 4 (輸入),HDMI x 1 (輸出)
    支援色彩 12 Bits / Color (Data Rate Up to 2.25Gbps)
    最大支援解析度 1080p
    按鍵數量 按鍵 x 8
    最大消耗電流 300mA
    電源變壓器 DC 5V 1A
    環境規格 工作溫度:0~55℃,儲存溫度:-20~85℃,相對濕度:最高95%
    尺寸   mm 253 x 138.5 x 40
    重量 g 770
    Product ID: HS04

    4 Input 1 Output HDMI Switcher

    Features:
    Switch easily between any four HDMI sources by remote control or push button front.
    HDMI 1.3a compliance, support Deep Color 12 Bits/Color (Data rate up to 2.25Gbps) and 3D capable.
    Extends the range of HDMI compliant device by equalizing and reclocking the HDMI signal.
    Supports high resolution input:
    HDTV: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p @60Hz.
    HDCP pass-through.
    LED brightness could be adjusted for different environment.
    Built in auto scan switching input function, to automatically select the next one with the signal of the input.
    Built in auto jump function, to automatically select the new video input.
    Easy to use front panel control of switching or using the included remote control.
    PC Remote control option model: RC01 RS232 to UART Converter. (Order separately).
    The switcher box is the ideal for all of devices, offering both high-definition video and audio switching capability.



    ITEM

    HS04

    Connector

    HDMI Type A

    Input / Output

    HDMI (Input) x 4、HDMI (Output) x 1

    Color depth

    12 Bits/Color (Data rate up to 2.25Gbps)

    Resolutions

    1080p (Max)

    Function Button

    Button x 8

    Power Supply

    5V DC.1000mA Regulated ( External )

    Power Consumption

    300mA ( Max )

    Dimensions

    253 x 138.5 x 40 (mm)

    Shipping Weight

    800 g
