商品型號: SP006
以太網絡電湧保護器
商品規格:
- 設備端:RJ45端子,線材端:RJ45端子+接地螺絲
- 四對絞線防雷保護
- 電腦網路設備如:電腦,伺服器等防雷專用
- 保護雙絞線產品(TTA111AV多功能傳輸及主動式VGA雙絞線延長器VE01)或任何利用網路線之電腦設備
產品規格 |
SP006 |
響應時間 |
1 ns |
最大放電壓 |
4 KV |
耐擊壽命 |
300 surges of 100A |
絕緣阻抗 |
10,000 MΩ |
瞬間接地阻抗 |
Approx,0Ω |
頻寬 |
0~1 GHz |
瞬間擷取電壓 |
AC / DC 130V,65 Vrms at10 A |
訊號插入損失 |
Less than 0,2 dB |
反匱損失 (75Ω) |
16dB |
轉接頭規格 |
RJ45 |
尺寸 mm |
67 x 87 x 27 |
重量 g |
126 |
Product ID: SP006
Network Surge Protection Device
Features:
- Performs a different function than grounding requirements.
- Protects equipment from high voltage surges from nearby lightning strikes.
- Two stage protection: under100ns – 90V, over 100ns-12V.
- Wide range of applications: CCTV system, Antenna of Television, satellite receivers, FM receivers, video camera, monitors, mulitiplexers & Quad processor, VCR, etc.
|
|
|
|
