商品規格:

• 電源輸入: AC 120/230V 電源輸出: 16路AC 24V 。
• 單路輸出500mA (平均)
• 每路內置短路保護&超載保護
• 內置PTC電源自動回復
• 使用環型變壓器效率佳溫度低安全性高

• ITEM NO.	PR816
  Port	16
  Output Voltage	AC 24V
  Output Current	0.5A/ Port
  Output Trip Current	1A / Port
  Short Cut Time	0.2 Sec/ Port
  Cut Current / Time	2.5A/ 4Sec
  Reset able Output	AUTO
  Reset able Output Time	1 Sec (Min)
  Total Output Current	8A (Max)
  DIMESIONS W × H × D mm	437×170×44
  WEIGHT kg.	4

• Product ID: PR816

  8 Amp 16 Port AC24V Power Supply in 1U Rack Mounting Panel

  Specifications:

  PR816 is AC24V (Non-Regulated) 8AMP power supply in 19” standard 1U rack mounting cabinet. It is perfect to install in the control room. Application for larger industry CCTV installation where need numbers of camera, housing, pan tilt turning device or other surveillance equipments power sources from control room.



  Features:

  • Sixteen port power supply, AC120V/230V to AC24V /0.5A (Max) output.
  • Each port output current 0.5A (Max).
  • Built in “no fuse breaker” to avoid current overload
  • Built in PTC (positive temperature coefficient) for short protection and auto rework on each port.

  　

  ITEM NO. PR816 Port 16 Output Voltage AC 24V Output Current 0.5A/ Port Output Trip Current 1A / Port Short Cut Time 0.2 Sec/ Port Cut Current / Time 2.5A/ 4Sec Reset able Output AUTO Reset able Output Time 1 Sec (Min) Total Output Current 8A (Max) DIMESIONS W × H × D mm 437×170×44 WEIGHT kg. 4 STORAGE TEMPERATURE -30℃~70℃ OPERATION TEMPERATURE -10℃~45℃
