    首頁 > > ALPHA-UL Hook-Up Wire (600V)電子連接線

    ALPHA3071 Awg 20 CA Prop 65, CSA TEW 105, UL 1015, UL MTW 電子線
    看原圖
    		ALPHA-3071


    商品編號: ALPHA3071, msn, google, yahoo

    ALPHA-3071 Awg 20 CA Prop 65, CSA TEW 105, UL 1015, UL MTW PVC 電子線

    Part # Voltage AWG Stranding Insulation Thickness Insulation Diameter Insulation Material Applicable Specifications
    3073 600 20 10/30 0.032 0.101 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    1) Component 1 1 X 1 HOOKUP 　
    a) Conductor 20 (10/30) AWG TC 0.037
    b) Insulation 0.032" Wall, Nom. PVC 0.101+/- 0.004
    (1) Print ALPHA WIRE E163872-* (UL) MTW 600V OR AWM STYLE
    1015 105C 600V VW-1 20 AWG ---- LLXXXX CSA TEW
    105C 600V FT1 ROHS
    * = Factory Code
    [Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
    (2) Color(s) WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN
    ORANGE, SLATE, VIOLET, GREEN/YELLOW
    Applicable Specifications
    1) UL AWM/STYLE 1015 105°C / 600 VRMS
    　 MTW 90°C Dry / 60°C Wet / 600 VRMS
    2) CSA International TEW-105 105°C / 600 VRMS
    Environmental
    1) EU Directive 2002/95/EC(RoHS):
    　 All materials used in the manufacture of this part are in compliance with EU Directive 2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.
    2) California Proposition 65: The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65.
    Properties
    Physical & Mechanical Properties
    1) Temperature Range -20 to 105°C
    2) Bend Radius 10X Cable Diameter
    3) Pull Tension 7.9 Lbs, Maximum
    Electrical Properties (For Engineering purposes only)
    1) Voltage Rating 600 VRMS
    2) Inductance 0.08 µH/ft, Nominal
    3) Conductor DCR 11.4 Ω/1000ft @20°C, Nominal
    Other
    Packaging Flange x Traverse x Barrel (inches)
    a) 1000 FT 6.5 x 6 x 1.9 Continuous length
    b) 100 FT 3.5 x 3 x 1.125 Continuous length
    　 [Spool dimensions may vary slightly]

    The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application— whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven, or off-road construction equipment.

    Our hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.

    EU/China ROHS CERTIFICATE OF COMPLIANCE
    To Whom It May Concern:
    Alpha Wire Part Number: 3073
    3073 , RoHS-Compliant Commencing With 1/1/2005 Production
    This document certifies that the Alpha part number cited above are manufactured in accordance with Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003, better known as the RoHS Directives, with regards to restrictions of the use of certain hazardous substances used in the manufacture of electrical and electronic equipment. The reader is referred to these Directives for the specific definitions and extents of these Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed part number is in compliance with the European Union’s Restriction of Hazardous Substances (RoHS) Directive, 2002/95/EC and all subsequent revisions and China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2006.
    Substance Maximum Control Value
    Lead 0.1% by weight (1000 ppm)
    Mercury 0.1% by weight (1000 ppm)
    Cadmium 0.01% by weight (100 ppm)
    Hexavalent Chromium 0.1% by weight (1000 ppm )
    Polybrominated Biphenyls (PBB) 0.1% by weight (1000 ppm)
    Polybrominated Diphenyl Ethers (PBDE) , 　
    Including Deca-BDE 0.1% by weight (1000 ppm)
    The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual usage of the product.
    Authorized Signatory for the Alpha Wire Company:
    Dave Watson, Director of Engineering & QA 1/8/2012
    Part # Voltage AWG Stranding Insulation Thickness Insulation Diameter Insulation Material Applicable Specifications
    alpha 3055/1 300 18 Solid 0.016 0.072 PVC CA Prop 65, CSA FT1, CSA TR 64, UL AWM 1007, UL AWM 1569, UL VW-1
    alpha 3057 300 16 26/30 0.016 0.092 PVC CA Prop 65, CSA FT1, CSA TR 64, UL AWM 1007, UL AWM 1569, UL VW-1
    alpha 3057/1 300 16 Solid 0.016 0.083 PVC CA Prop 65, CSA FT1, CSA TR 64, UL AWM 1007, UL AWM 1569, UL VW-1
    alpha-3070 600 24 7/32 0.032 0.088 PVC CA Prop 65, CSA TEW 105, UL AWM 1015
    Alpha 3071 600 22 7/30 0.032 0.094 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha 3073 600 20 10/30 0.032 0.101 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha-3075 600 18 16/30 0.032 0.111 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha-3077 600 16 26/30 0.032 0.124 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha-3079 600 14 41/30 0.032 0.138 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha 3080 600 12 65/30 0.032 0.157 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha3081 600 10 105/30 0.032 0.184 PVC CA Prop 65, CSA TEW 105, UL AWM 1015, UL MTW
    alpha 3111000 600 10 105/30 0.03 0.223 Mica/Glass CSA AWM, UL 5107
    alpha-3111265 600 12 65/30 0.025 0.161 Mica/Glass CSA AWM, UL 5107
    alpha3111441 600 14 41/30 0.025 0.144 Mica/Glass CSA AWM, UL 5107
    alpha3111626 600 16 26/30 0.025 0.128 Mica/Glass CSA AWM, UL 5107
    alpha-3111816 600 18 16/30 0.025 0.117 Mica/Glass CSA AWM, UL 5107
    alpha 3112010 600 20 10/30 0.025 0.106 Mica/Glass CSA AWM, UL 5107
    alpha 3112133 600 2 133/23 0.035 0.444 Mica/Glass CSA AWM, UL 5107
    alpha3114133 600 4 133/25 0.03 0.361 Mica/Glass CSA AWM, UL 5107
    alpha-3116133 600 6 133/27 0.03 0.305 Mica/Glass CSA AWM, UL 5107
