    Thermocouple Wire E-TYPE Seriors
    看原圖
    IDA-E-TYPE


    商品編號: IDA-E-TYPE

    Thermocouple Wire E-TYPE Seriors



    The wire can be used in various thermal places ranging from household appliances, lighting devices, industrial machines, to high-temperature furance

    E-TYPE Specifications


    Wire Code Specification Dimension Insulation Material Conductor Material Temperature Range Mt/ Coils
    ID (mm) OD (mm) H x L (+) (-)
    PP-KC-22S 0.3/4 x 2 (22 AWG) 1.45 2.40 x 3.75 PVC Copper Ni-Copper 0 ~ 105C 200
    PP-KC-20S 0.3/7 x 2 (20 AWG) 1.50 2.40 x 3.75 PVC Copper Ni-Copper 0 ~ 105C 200
    PP-KC-16S 0.6/4 x 2 (16 AWG) 2.45 4.50 x 7.00 PVC Copper Ni-Copper 0 ~ 105C 200
    PP-KC-14S 0.6/7 x 2 (14 AWG) 3.00 4.55 x 7.65 PVC Copper Ni-Copper 0 ~ 105C 200
    PSP-KC-14S 0.6/7 x 2 (14 AWG) 3.00 4.90 x 7.80 PVC-SUS304 Copper Ni-Copper 0 ~ 105C 200
    SPP-KC-14S 0.6/7 x 2 (14 AWG) 3.00 5.80 x 8.20 PVC-SUS304 Copper Ni-Copper 0 ~ 105C 200
    GG-KX-28 0.3 x 2 (28 AWG) 0.75 1.40 x 2.50 Fiberglass Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    GG-KX-22 0.6 x 2 (22 AWG) 1.10 2.00 x 3.20 Fiberglass Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    GG-KC-22S 0.3/4 x 2 (22 AWG) 1.20 2.05 x 3.30 Fiberglass Copper Ni-Copper 0 ~ 200C 200
    GG-KC-20S 0.3/7 x 2 (20 AWG) 1.50 2.00 x 3.50 Fiberglass Copper Ni-Copper 0 ~ 200C 200
    GG-KC-16S 0.6/4 x 2 (16 AWG) 2.15 3.00 x 4.60 Fiberglass Copper Ni-Copper 0 ~ 200C 200
    GG-KC-14S 0.6/7 x 2 (14 AWG) 2.40 3.30 x 5.20 Fiberglass Copper Ni-Copper 0 ~ 200C 200
    SGG-KX-24 0.5 x 2 (24 AWG) 1.00 1.65 x 2.85 Fiberglass-SUS304 Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    SGG-KX-22 0.6 x 2 (22 AWG) 1.10 1.75 x 2.95 Fiberglass-SUS305 Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    SGG-KX-22S 0.3/4 x 2 (22 AWG) 1.20 1.80 x 3.05 Fiberglass-SUS306 Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    HH-K-36 0.127 x 2 (36 AWG) 0.50 0.95 x 1.45 Silica Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 710C 200
    HH-K-30 0.254 x 2 (30 AWG) 0.65 1.10 x 1.55 Silica Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 710C 200
    HH-K-24 0.5 x 2 (24 AWG) 1.00 1.20 x 1.90 Silica Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 710C 200
    HH-K-22 0.6 x 2 (22 AWG) 1.10 1.70 x 2.70 Silica Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 710C 200
    HH-K-20 0.8 x 2 (20 AWG) 1.30 1.75 x 2.75 Silica Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 710C 200
    CC-K-24 0.5 x 2 (24 AWG) 1.00 1.50 x 2.50 Ceramics Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 1200C 200
    CC-K-20 0.8 x 2 (20 AWG) 1.30 1.75 x 2.75 Ceramics Fiber Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 1200C 200
    TT-KX-36 0.127 x 2 (36 AWG) 0.29 0.42 x 0.75 Teflon Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    TT-KX-28 0.3 x 2 (28 AWG) 0.65 1.00 x 1.65 Teflon Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    TT-KX-24 0.5 x 2 (24 AWG) 0.85 1.20 x 1.85 Teflon Chromel
    Ni-Cr
    Alumel
    Ni-Al
    1 ~ 200C 200
    TT-KX-22 0.6 x 2 (22 AWG) 1.05 1.75 x 2.75 Teflon Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 200C 200
    KK-K-24
    KK-K-24S
    0.5 x 2 (24 AWG)
    0.2/7 x 2 (24 AWG)
    1.00 1.20 x 2.20 KAPTON Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 400C 200
    KK-K-20 0.8 x 2 (20 AWG) 1.30 2.00 x 3.00 KAPTON Chromel
    Ni-Cr
    Alumel
    Ni-Al
    0 ~ 400C 200
    • TECHNICAL DATA
    • Material:PVC , Temp Range:-10 ~ 105C , Flame Retardant:Bad ,Friction Resist.:Good , Oil Resist.:Bad , Chemical Resist.:Fair , Waterproof:Good , Flexibility:Excellent
    • Material:EPR/HYP Rubber , Temp Range:-15 ~ 110C , Flame Retardant:Bad ,Friction Resist.:Good ,Oil Resist.:Good , Chemical Resist.:Good ,Waterproof:Good , Flexibility:Excellent
    • Material:Silicone , Temp Range:-60 ~ 200C , Flame Retardant:Good , Friction Resist.:Good , Oil Resist.:Excellent ,Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Excellent
    • Material:Silicone Waker 750 , Temp Range:-60~300C , Flame Retardant:Good , Friction Resist.:Good , Oil Resist.:Excellent , Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Excellent
    • Material:Teflon FEP , Temp Range:-100 ~ 200C , Flame Retardant:Excellent , Friction Resist.:Excellent , Oil Resist.:Excellent , Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Good
    • Material:Teflon PFA , Temp Range:-267 ~ 260C , Flame Retardant:Excellent , Friction Resist.:Excellent , Oil Resist.:Excellent , Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Good
    • Material:KAPTON , Temp Range:-267 ~ 316C , Flame Retardant:Good , Friction Resist.:Good , Oil Resist.:Good , Chemical Resist.:Good , Waterproof:Fair , Flexibility:Fair
    • Material:Fiberglass , Temp Range:-100 ~ 500C , Flame Retardant:Excellent , Friction Resist.:Fair , Oil Resist.:Fair , Chemical Resist.:Excellent , Waterproof:Bad , Flexibility:Fair
    • Material:Fiberglass , Temp Range:-100 ~ 710C , Flame Retardant:Excellent , Friction Resist.:Fair , Oil Resist.:Fair , Chemical Resist.:Excellent , Waterproof:Bad , Flexibility:Fair
    • Material:Ceramic Fiber , Temp Range:-100 ~ 1200C , Flame Retardant:Excellent , Friction Resist.:Bad , Oil Resist.:Fair , Chemical Resist.:Excellent , Waterproof:Bad , Flexibility:Fair
