商品編號: Harbour-HP4
NEMA HP-4 TYPES K, KK, KT Replaces M16878/11, /12, /13 電子線
Up to 1000 V and 200° C. Gauge sizes from 30 AWG to 6 AWG. Replaces M16878/11 thru /13
|
|
NEMA HP-4 TYPES K, KK, KT
Replaces M16878/11, /12, /13
Construction
Stranded or solid tin or silver plated copper
Extruded FEP
Ratings/Approvals
TPC 150° C SPC 200º C
NEMA HP-3 has no requirement for the wire to be printed.
For use in internal wiring of electronic equipment and appliances. HP-3 & HP-4 lead wires have a low coefficient of friction which promotes easy handling. The insulation also resists hot soldering irons, is self extinguishing, non-flammable, has excellent chemical resistance and is suitable for immersion in gasoline, gasoline vapor and oil (at 80º C maximum). Weathering, ozone and most corrosive environments do not affect PTFE or FEP insulation.
對於電子設備和電器內部佈線使用。 HP-3,HP-4引線具有摩擦促進易於處理係數低。絕緣還抵抗熱烙鐵,是自熄的,不易燃,具有優異的耐化學性和適於浸入汽油,汽油蒸汽和油(在80ºC的最高)。風化,臭氧和最腐蝕性的環境不會影響的PTFE或FEP絕緣。
|
|
|
|
