商品編號: TC-127C
TC-127C Handheld thermometer Dual input thermocouple with data logging K/J/T/E/R/S/N Types 雙輸入熱電耦儲存式多功能溫度測試儀器
TC-127C Handheld thermometer
Dual input thermocouple with data logging
|
K/J/T/E/R/S/N TYPES |
FEATURES : |
4 1/2 digital counts with triplet displays. |
Resolution: 0.1°C / 0.1°F. |
Function: |
°C/°F, MAX, MIN, HOLD, REL, ADJ, LIMIT Hi/Lo, TYPE, TIME,
T1-T2, BACK LIGHT,REC, CALL(Consult the Recorded data),
9 sections of reservations record is set up. |
Sampling Rate: 4 times/sec.
|
Auto power off. |
The electric capacity of 5 sections of batteries shows. |
IR to USB Data Transfer Output & Software. |
Software Included (Windows® 2000, XP, VISTA, 7 Compatible) |
PC software is simple and easy to operate. |
Software can convert English, Traditional Chinese and Simplified Chinese display. |
Data Logging Capacity 9999 per Channel. |
CALL-Fit to quick read memory data. |
Temperature offset adjust. (Can resume the initial value function temporarily or forever). |
Record interval and measurement period setting. |
Warning beeper with Hi/Lo setting. |
TIME setting, REL setting. |
Real time clock with calender. |
Battery Life : 200 hours(Alkaline Battery). |
CE-Mark approval. Conform to ITS-90. |
TC-127C is offered for a long time & electric consumption in provinces measure mode. (Mode 2 of save electricity, approximately 6 months. Record interval = 15 minutes / alkaline battery.)
|
|
|
|
|
|
SPECIFICATIONS: |
Thermocouple range
|
K Type: -200°C ~ 1372°C (-328°F ~ 2501°F)
J Type: -210°C ~ 1200°C (-346°F ~ 2192°F)
T Type: -250°C ~ 400°C (-418°F ~ 752°F)
E Type: -210°C ~ 1000°C (-346°F ~ 1832°F)
R/S Type: 0°C ~ 1767°C (32°F ~ 3212°F)
N Type: -150°C ~ 1300°C (-238°F ~ 2372°F) |
Accuracy (18°C ~ 28°C ambient)
|
K/J/E/T Type:
± (0.05% rdg + 0.3°C) -200°C ~ 1372°C
± (0.05% rdg + 0.6°F) -328°F ~ 2501°F
R/S Type:
± (0.05% rdg + 2°C) 0°C ~ 1767°C
± (0.05% rdg + 4°F) 32°F ~ 3212°F
N Type:
± (0.05% rdg + 1.5°C) -150°C ~ 1300°C
± (0.05% rdg + 3°F) -238°F ~ 2372°F |
Operation temperature and humidity
|
0°C ~ 50°C (32°F ~122°F), 0 ~80% RH |
Storage temperature and humidity
|
-20°C ~ 60°C(-4°F ~ 140°F), 0 ~ 80% RH |
Power requirement
|
R03(AB) SIZE AAA/1.5V/UM-4 x 4 pcs |
Input protection at thermocouple input
|
24V AC/DC Maximum |
Dimension (Without holster)
|
169 mm X 76 mm x 32 mm. |
Weight (Without holster)
|
Approx. 270g |
ACCESSORIES: |
R03(AB) Size AAA / 1.5V1UM-4 x 4 pcs
Holster x 1pc
K Type thermocouple x 2 pcs
User’s manual x 1 pc
USB transmission wire x 1pc
Temp Monitor 1 software CD x 1pc |
TC-127C 熱電耦儲存式多功能溫度錶 |
K/J/T/E/R/S/N TYPES
|
特點說明 : |
4 - 1/2 數位 與三顯示. |
解析度: 0.1° / 0.1°F |
功能設定: |
攝氏/華氏,最大值,最小值,讀值鎖定,歸零調整,相對值, 警示高溫/低溫,九段預約記錄設定,時間設定,萬年曆,T1減T2,背光,記錄,查閱記錄資料. |
取樣率: 每秒4次. |
自動/手動關機,五段電池電力容量顯示. |
紅外線傳輸界面 USB 傳輸線與視窗軟體. |
軟體支援WINDOWS 7 / VISTA / XP / 2000. |
PC軟體簡單好操作,可轉換英語,繁體中文,簡體中文顯示. |
每輸入可記錄9999筆資料. |
方便容易查閱記錄資料-提供快速查詢記錄資料. |
溫度歸零調整(提供暫時和永久及恢復初值功能). |
記錄間隔時間設定 . |
蜂鳴器警示,高溫 / 低溫設定. |
相對溫度值(可設定相對值). |
附有萬年曆功能設定. |
CE認證通過. 符合ITS-90規範. |
|
|
|
特性 : |
溫度測量範圍 |
K Type: -200°C ~ 1372°C (-328°F~2501°F)
J Type: -210°C ~ 1200°C (-346°F~2192°F)
T Type: -250°C~ 400 °C (-418°F~ 752°F)
E Type: -210°C~ 1000°C (-346°F~ 1832°F)
R/S Type: 0°C ~ 1767°C (32°F ~ 3212°F)
N Type: -150°C ~ 1300°C (-238°F ~ 2372°F) |
精確度: (18°C ~ 28°C 環境溫度)
|
K/J/E/T/N Type:
± (0.05% 讀值 + 0.3°C)
± (0.05% 讀值 + 0.6°F)
R/S Type:
± (0.05% 讀值 + 2°C)
± (0.05% 讀值 + 4°F) |
讀值顯示更新 |
每秒4次 |
記錄筆數 |
每輸入通道最多9999筆 |
電池壽命
|
一般模式: 約250小時/鹼性電池
節電模式一: 約3000小時 (interval = 15分鐘)/鹼性電池
節電模式二: 約7個月 (interval = 15分鐘)/鹼性電池 |
工作溫濕度
|
0°C ~ 50°C (32°F ~122°F), 0 ~ 80% RH |
儲藏溫濕度
|
-10°C ~ 60°C (14°F ~ 140°F), 0 ~ 70% RH |
電力供應
|
R03(AB) SIZE AAA/1.5V/UM-4 x 4PCS |
最大輸入端保護電壓
|
最大輸入交流/直流 24V |
外觀尺寸 (含保護套)
|
169 mm X 76 mm x 32 mm. |
重量 (含供護套,電池) |
約450公克 |
一般配件
|
使用手冊x1
R03(AB) SIZE AAA/1.5V/UM-4電池x4
保護套x1
K 型熱電耦x2
Temp Monitor 1軟體光碟x1
IrDA to USB傳輸線x1 |
|
|
|
|
|
|
