OPTICAL:
Transmitter Wavelength 850 ± 30nm (1310nm optional)
OSD418T Transmitter Coupled Power >-15dBm into multimode fiber (OSD418T)
> -13dBm into singlemode fiber (OSD418TL only)
OSD418R Transmitter Coupled Power >-20dBm into multimode fiber (OSD418R)
> -20dBm into singlemode fiber (OSD418RL only)
OSD418R Receiver Saturation >-12dBm
Transmission Distance >5km for multimode, >40km for singlemode
Receiver Operating Wavelength 800 to 900nm (1270 to 1580nm for OSD418TL and OSD418RL)
OSD418T Sensitivity for <-40dBm
1 x 10
-9
BER
Optical Connectors ST standard, others optiona |
|
|
|
