OPTICAL:
Transmitter Wavelength 850 ± 30nm (1310nm optional)
OSD420T Transmitter Coupled Power >-15dBm into multimode fiber (OSD420T)
> -20dBm into singlemode fiber (OSD420TL only)
OSD420R Transmitter Coupled Power >-20dBm into multimode fiber (OSD420R)
> -20dBm into singlemode fiber (OSD420RL only)
OSD420R Receiver Saturation >-12dBm
Receiver Operating Wavelength 800 to 900nm (1270 to 1580nm for OSD420TL and OSD420RL)
OSD420T Sensitivity for >50dB <-40dBm
Audio SNR and 1 x 10
-9
BER
Transmission Distance >5km for multimode, >40km for singlemode
Optical Connectors ST standard, others optional |
|
|
|
