OPTICAL:
Transmitter Wavelength: 850nm (1310nm for OSD8815TL)
OSD8815T Transmitter Coupled Power: >-15dBm into multimode fiber
> -15dBm into singlemode fiber (OSD8815TL only)
OSD8815R Receiver Sensitivity: <-27dBm
OSD8815R Receiver Saturation: >-3dBm
Link Distances: >3km multimode for standard 850nm OSD8815 link
(fiber bandwidth limited)
> 30km singlemode for optional 1310nm OSD8815L link
(fiber loss limited)
Optical Connector: ST standard, others optional |
|
|
|
