    Teldor 62X4426xxx 26 AWG XL ETFE 600V Lightweight Wall Flexible Conductor per MIL-W-22759/44電子線 Military & Defense
    看原圖
    		TELDOR-62X4426XXX

    商品編號: Teldor-62X4426xxx

    Teldor-62X4426xxx 26 AWG XL ETFE 600V Lightweight Wall Flexible Conductor per MIL-W-22759/44電子線 Military & Defense


    26 AWG XL ETFE 600V Lightweight Wall Flexible Conductor per MIL-W-22759/44

    Part Number:
    62X4426xxx
    　
    Applications: Multiple/Rapid deployment
    General Construction:
    26 AWG, XL ETFE  insulated flexible conductors complies to
    MIL-W-22759/44.
    Wires insulated with XL ETFE are resistant to acids, alkalis, oil, solvents, fungi and flame propagation.
    Outer Diameter: 0.81 mm nom.
    Weight: 2.08 kg/km

    Design & Materials
    Conductor Material: Silver-plated Copper
    Conductor Size: 26 AWG
    Conductor Construction: 19x0.10 mm
    Insulation Material: XL ETFE -65°C to 200°C
    Conductor Color Code: Insulation colors – Single Conductors
    Standards
    Standards: RoHS 2002/95/EC
    Flamability Rating: IEC 60332-1, UL 1581 VW-1
    Performance
    Max. DC Resistance : 132.9 Ω/km@20°C
    Dielectric Strength: 2000 V/minute
    Voltage Rating: 600 V
    Max. Operating Temperature: +200 °C
    Min. Operating Temperature: -65 °C
