    BELDEN-DEIP162U, DEIP162U - Indoor Digital Electricity Copper Cable, #16-2pr, TC, LS-PVC, CMP, LS-PVC Jkt remote powering, 屋內型遠端供電數位電力電纜
    看原圖
    		BELDEN-DEIP162U

    BELDEN-DEIP162U

    BELDEN-DEIP162U,  Indoor Digital Electricity Copper Cable, #16-2pr, TC, LS-PVC, CMP, LS-PVC Jkt       remote powering 屋內型遠端供電數位電力電纜

    Indoor Digital Electricity Copper Cable, 2-16 AWG Stranded (19x29) Tinned Copper Pairs with Flamarrest® insulation, Plenum-CMP, Flamarrest® Jacket with Ripcord

    百通數字電纜

      ⊕減少安裝時間：雙絞線可輕鬆識別電纜對，從而加快安裝速度並減少混亂

      ⊕更少的電纜浪費：默認捲軸長度為2,000 ft：典型的走線長度超過500 ft，導致傳統捲軸長度為1,000 ft的大量廢物

      ⊕靈活性：適用於室內，室外，低煙零鹵素和潮濕場所

      ⊕減少庫存的電纜：混合結構意味著您可以通過庫存和管理兩根電纜來減少庫存，而管理一根電纜則可以減少庫存

      ⊕單根電纜拉線節省時間：使用混合結構，您只需要拉一條單根電纜與兩條電纜即可，從而降低了人工成本

    數字電力應用

     ⊕遠距離供電：與直流電源或以太網供電（PoE）相比，在更長的距離內提供更多的功率

     ⊕ 安全：可以觸摸，沒有危險的電擊危險

     ⊕ 具有成本效益：無管道，低成本勞動力；電纜安裝不需要電工

     ⊕部署速度：靈活性，部署速度和變更速度

     ⊕節省空間：減少房地產需求–將IDF壁櫥旁路到區域


    Product Overview

    Suitable Applications: Digital Electricity™, remote powering

    Physical Characteristics (Overall)


    Conductor
    AWG Stranding Material No. of Pairs
    16 19x29 TC - Tinned Copper 2
    Conductor Count: 16
    Total Number of Pairs: 2

    Insulation
    Material Material Trade Name Nominal Wall Thickness
    PVC - Polyvinyl Chloride Flamarrest® 0.011 in

    Color Chart
    Number Color
    1 Black & Red
    2 Black & White

    Outer Jacket Material
    Material Nominal Diameter Nominal Wall Thickness
    PVC - Polyvinyl Chloride 0.326 in 0.017 in

    Electrical Characteristics


    Conductor DCR
    Nominal Conductor DCR
    4.3 Ohm/1000ft

    Capacitance
    Nom. Capacitance Conductor to Conductor
    30 pF/ft

    Current
    Max. Recommended Current [A]
    8.75 Amps per Conductor at 25ºC (35°C Temperature Rise)

    Voltage
    UL Voltage Rating
    300 V RMS

    Temperature Range

    UL Temp Rating: 75°C
    Operating Temp Range: 0°C To +75°C

    Mechanical Characteristics

    Bulk Cable Weight: 52 lbs/1000ft
    Max. Pull Tension: 121.5 lbs
    Min Bend Radius/Minor Axis: 3.25 in

    Standards

    NEC Articles: Article 800
    NEC/(UL) Compliance: CMP
    CEC/C(UL) Compliance: CMP

    Applicable Environmental and Other Programs

    EU Directive 2000/53/EC (ELV): Yes
    EU Directive 2003/11/EC (BFR): Yes
    EU Directive 2011/65/EU (ROHS II): Yes
    EU Directive 2012/19/EU (WEEE): Yes
    EU Directive 2015/863/EU: Yes
    EU Directive Compliance: EU Directive 2003/11/EC (BFR)
    EU CE Mark: Yes
    EU REACH SVHC Compliance (yyyy-mm-dd): 2019-05-13
    EU RoHS Compliance Date (yyyy-mm-dd): 2019-05-13

    Suitability

    Suitability - Indoor: Yes

    Flammability, LS0H, Toxicity Testing

    C(UL) Flammability: FT6
    UL Flammability: NFPA 262

    Part Number


    Variants
    Item # Color Length
    DEIP162U Apple Green 2,000 ft
