    首頁 > > Belden-Audio-Control-Cable(音響控制線)

    Belden8473 AWG14 1Pair High-Conductivity Copper Speaker Cable 廣播聲音音響, 儀表控制電纜
    看原圖
    		453118

    商品編號: Belden-8473

    8473 Paired - High-Conductivity Copper Speaker Cable      廣播聲音音響, 儀表控制電纜

    14 AWG stranded (42x30) tinned copper conductors, PVC insulation, twisted pair, PVC jacket.
    8473
    		    Multi-Conductor - High-Conductivity Copper Speaker Cable Twisted Jacketed Con
    14 AWG stranded (42x30) tinned copper conductors, PVC insulation, twisted pair, PVC jacket.    		 For more Information
    please call

    1-800-Belden1
    Put Ups and Colors:
    Item # Putup Ship Weight Color Notes Item Desc
    8473 060U500 500 FT 29.000 LB CHROME 　 1 PR #14 PVC PVC
    8473 0601000 1,000 FT 58.000 LB CHROME C 1 PR #14 PVC PVC
    8473 060500 500 FT 30.500 LB CHROME C 1 PR #14 PVC PVC
    Notes: 　
    C = CRATE REEL PUT-UP.
    　
    Physical Characteristics (Overall)
    Conductor
    AWG:
    # Pairs AWG Stranding Conductor Material
    1 14 42x30 TC - Tinned Copper
    Insulation
    Insulation Material:
    Insulation Material Wall Thickness (in.)
    PVC - Polyvinyl Chloride .031
    Insulation Resistance: 1000 Megohms/1000 ft. @ 500 VDC
    Outer Shield
    Outer Shield Material:
    Outer Shield Material
    Unshielded
    Outer Jacket
    Outer Jacket Material:
    Outer Jacket Material Nom. Wall Thickness (in.)
    PVC - Polyvinyl Chloride .032
    Overall Cabling
    Overall Nominal Diameter: 0.340 in.
    Pair
    Pair Color Code Chart:
    Number Color
    1 Black & White
    Pair Lay Length & Direction:
    Lay Length (in.) Twists/ft. (twist/ft)
    2.000 6.000
    Mechanical Characteristics (Overall)
    Operating Temperature Range: -20°C To +90°C
    Non-UL Temperature Rating: 90°C (UL AWM Style 2587)
    Bulk Cable Weight: 52.600 lbs/1000 ft.
    Max. Recommended Pulling Tension: 94 lbs.
    Min. Bend Radius (Install)/Minor Axis: 3.500 in.
    Applicable Specifications and Agency Compliance (Overall)
    Applicable Standards & Environmental Programs
    NEC/(UL) Specification: CL3
    AWM Specification: UL Style 2587 (600 V 90°C)
    EU CE Mark: Yes
    EU Directive 2000/53/EC (ELV): Yes
    EU Directive 2002/95/EC (RoHS): Yes
    EU RoHS Compliance Date (mm/dd/yyyy): 04/01/2005
    EU Directive 2002/96/EC (WEEE): Yes
    EU Directive 2003/11/EC (BFR): Yes
    CA Prop 65 (CJ for Wire & Cable): Yes
    MII Order #39 (China RoHS): Yes
    Flame Test
    UL Flame Test: UL1685 UL Loading
    CSA Flame Test: FT1
    Plenum/Non-Plenum
    Plenum (Y/N): No
    Electrical Characteristics (Overall)
    Nom. Inductance:
    Inductance (µH/ft)
    0.19
    Nom. Capacitance Conductor to Conductor:
    Capacitance (pF/ft)
    33
    Nom. Conductor DC Resistance:
    DCR @ 20°C (Ohm/1000 ft)
    2.86
    Max. Operating Voltage - UL:
    Voltage Description
    600 V RMS UL AWM Style 2587
    300 V RMS CL3
    Max. Recommended Current:
    Current
    9.6 Amps per conductor @ 25°C (10°C rise in temp)
    Notes (Overall)
    Notes: Nominal Breakdown Voltage - Jacket 20 KV RMS; Nominal Breakdown Voltage Between Conductors 25 KV RMS. See NEC guidelines for applicable CL3 voltage ratings.
