商品編號: Belden-36100
Belden-36100 AWG 2/0 Hook-up/Lead - 5000V High-Voltage Hypalon®海巴龍耐高壓電線
This insulation is chlorosulphonated polyethylene. Hypalon® insulation has excellent heat resistance, color stability and electrical properties.
36100 |
|
Hook-up/Lead - 5000V High-Voltage Hypalon®
This insulation is chlorosulfonated polyethylene. Hypalon® insulation has excellent heat resistance, color stability and electrical properties. |
For more Information
please call
1-800-Belden1 |
Item # |
Putup |
Ship Weight |
Color |
Notes |
Item Desc |
36100 01050 |
50 FT |
37.450 LB |
BLACK |
C |
#2/0 STR CSM BLK |
|
Notes: |
|
C = CRATE REEL PUT-UP.
|
Physical Characteristics (Overall)
Conductor
AWG:
# Conductors |
AWG |
Stranding |
Conductor Material |
1 |
2/0 |
504x26 |
TC - Tinned Copper |
|
Insulation
Insulation Material:
Insulation Trade Name |
Insulation Material |
Wall Thickness (in.) |
Hypalon® |
Chlorosulphonated Polyethylene |
.150 |
|
Separator
Separator Material over Conductor: |
Y |
Overall Insulation
Overall Cabling
Overall Nominal Diameter: |
0.815 in. |
Mechanical Characteristics (Overall)
Non-UL Temperature Rating: |
105°C |
Bulk Cable Weight: |
639 lbs/1000 ft. |
Applicable Specifications and Agency Compliance (Overall)
Applicable Standards & Environmental Programs
EU Directive 2000/53/EC (ELV): |
Yes |
EU Directive 2002/95/EC (RoHS): |
Yes |
EU RoHS Compliance Date (mm/dd/yyyy): |
01/01/2004 |
EU Directive 2002/96/EC (WEEE): |
Yes |
EU Directive 2003/11/EC (BFR): |
Yes |
CA Prop 65 (CJ for Wire & Cable): |
Yes |
MII Order #39 (China RoHS): |
Yes |
Plenum/Non-Plenum
Notes (Overall)
Notes: |
Hypalon - Trademark of DuPont |
Notes (Cont'd.): |
Exact strand count may vary. |
|
|
|
|
