Belden31500 Hook-up/Lead - Awg 2/0 UL AWM Style 3049 600V, 90°C 鳥波林電子線

455503

商品編號: Belden-31500

Belden31500 Hook-up/Lead - Awg 2/0 UL AWM Style 3049 600V, 90°C 鳥波林電子線

DESCRIPTION:
Neoprene insulation has good heat aging characteristics and is an excellent low-cost motor lead wire. It may be considered for use in hazardous locations and is being used in explosion-proof motors recognized by UL.

PHYSICAL CHARACTERISTICS :

CONDUCTOR :
Number of Conductors: 1
Total Number of Conductors: 1
AWG: 2/0
Stranding: 504x26
Conductor Material: TC - Tinned Copper

SEPARATOR :
Separator Material over Conductor: Y

INSULATION :
Insulation Material: Neoprene
Insulation Thickness: .080 in.

OVERALL :
Overall Nominal Diameter: .668 in.
MECHANICAL CHARACTERISTICS :

Non-UL Temperature Rating: 90°C
Recommended Maximum Baking Cycles: 24 Hours @ 300°F (149°C) ~ 8 Hours @ 325°F (163°C) ~ 15 Minutes @ 450°F (232°C)
APPLICABLE SPECIFICATIONS AND AGENCY COMPLIANCE :

APPLICABLE STANDARDS :
UL AWM Style: 3049
UL Rating: 600 V, 90°C
EU RoHS Compliant (Y/N): Yes
EU RoHS Compliance Date (mm/dd/yyyy):: 01/01/2004

PLENUM/NON-PLENUM :
Plenum (Y/N): N
PUT-UPS AND COLORS:

Item Description Put-Up (ft.) Ship Weight (lbs.) Jacket Color Notes
31500 010250 #2/0 STR CR 90C 600V 250 141.5 BLACK C F

C = CRATE REEL PUT-UP.
F = MAY CONTAIN MORE THAN 1 PIECE. MINIMUM LENGTH OF ANY ONE PIECE IS 50'
