Belden-89259 RG59 22 AWG stranded FEP Coaxial - 75 Ohm RG59 鐵氟龍耐高溫同軸電纜

162783

商品編號: Belden-89259

Belden-89259 RG59 22 AWG stranded FEP Coaxial - 75 Ohm RG59 鐵氟龍耐高溫同軸電纜

89259

Coax - 75 Ohm Coax
22 AWG stranded (7x30) .030" bare copper conductor, plenum, foam FEP insulation, bare copper braid shield (95% coverage), FEP jacket.

For more Information
please call

1-800-Belden1

Put Ups and Colors:

Item #	Putup	Ship Weight	Color	Notes	Item Desc
89259 010100	100 FT	5.100 LB	BLACK		#22 COAX FEP RG59/U
89259 0101000	1,000 FT	32.000 LB	BLACK	C	#22 COAX FEP RG59/U
89259 010500	500 FT	16.000 LB	BLACK	C	#22 COAX FEP RG59/U

Notes:
C = CRATE REEL PUT-UP.

Physical Characteristics (Overall)

Conductor

AWG:

# Coax	AWG	Stranding	Conductor Material	Dia. (in.)
1	22	7x30	BC - Bare Copper	.030

Insulation

Insulation Material:

Insulation Material	Dia. (in.)
FFEP - Foam Fluorinated Ethylene Propylene	.135

Outer Shield

Outer Shield Material:

Type	Outer Shield Material	Coverage (%)
Braid	BC - Bare Copper	95

Outer Jacket

Outer Jacket Material:

Outer Jacket Material

FEP - Fluorinated Ethylene Propylene

Overall Cabling

Overall Nominal Diameter:

0.193 in.

Mechanical Characteristics (Overall)

Operating Temperature Range:

-70°C To +200°C

Non-UL Temperature Rating:

200°C

Bulk Cable Weight:

32 lbs/1000 ft.

Max. Recommended Pulling Tension:

70 lbs.

Min. Bend Radius (Install)/Minor Axis:

2.500 in.

Applicable Specifications and Agency Compliance (Overall)

Applicable Standards & Environmental Programs

NEC/(UL) Specification:

CMP

CEC/C(UL) Specification:

CMP

EU CE Mark:

EU Directive 2000/53/EC (ELV):

Yes

EU Directive 2002/95/EC (RoHS):

Yes

EU RoHS Compliance Date (mm/dd/yyyy):

04/01/2005

EU Directive 2002/96/EC (WEEE):

Yes

EU Directive 2003/11/EC (BFR):

Yes

CA Prop 65 (CJ for Wire & Cable):

Yes

MII Order #39 (China RoHS):

Yes

RG Type:

59/U

Flame Test

UL Flame Test:

NFPA 262

C(UL) Flame Test:

FT6

Suitability

Suitability - Outdoor:

Yes

Suitability - Burial:

Yes

Plenum/Non-Plenum

Plenum (Y/N):

Yes

Non-Plenum Number:

9259

Electrical Characteristics (Overall)

Nom. Characteristic Impedance:

Impedance (Ohm)

Nom. Inductance:

Inductance (µH/ft)

.092

Nom. Capacitance Conductor to Shield:

Capacitance (pF/ft)

17.3

Nominal Velocity of Propagation:

VP (%)

Nominal Delay:

Delay (ns/ft)

1.3

Nom. Conductor DC Resistance:

DCR @ 20°C (Ohm/1000 ft)

Nominal Outer Shield DC Resistance:

DCR @ 20°C (Ohm/1000 ft)

2.6

Nom. Attenuation:

Freq. (MHz)	Attenuation (dB/100 ft.)
1	.3
10	.9
50	2.1
100	3.0
200	4.5
400	6.6
700	9.0
900	10.1
1000	11.0

Max. Operating Voltage - UL:

Voltage

300 V RMS
