Belden9899 AWG18 UL/1855 5000 V, 80°C PVC Hook-up/Lead - Test Prod Wire 探針測試棒電子線

455481

商品編號: Belden9899 , google,yahoo,pchome

Belden-9899 AWG18 UL/1855 5000 V, 80°C PVC Hook-up/Lead - Test Prod Wire UL美國規格探針測試棒電線

9899

Hook-up/Lead - Test Prod Wire
Tinned copper conductor, PVC insulation. Use test probe leads for electrical and electronic measuring for test equipment.

For more Information
please call

1-800-Belden1

Put Ups and Colors:

Item #	Putup	Ship Weight	Color	Notes	Item Desc
9899 002100	100 FT	2.100 LB	RED		#18 STR PVC TEST PROD RED
9899 0021000	1,000 FT	15.000 LB	RED		#18 STR PVC TEST PROD RED
9899 002500	500 FT	7.500 LB	RED		#18 STR PVC TEST PROD RED
9899 005500	500 FT	7.500 LB	GREEN, DARK		#18 STR PVC TEST PROD DGRN
9899 009500	500 FT	7.500 LB	WHITE		18 STR PVC TEST PROD WHT
9899 010100	100 FT	2.100 LB	BLACK		#18 STR PVC TEST PROD BLK
9899 0101000	1,000 FT	15.000 LB	BLACK	C	#18 STR PVC TEST PROD BLK
9899 010500	500 FT	7.500 LB	BLACK		#18 STR PVC TEST PROD BLK

Notes:
C = CRATE REEL PUT-UP.

Physical Characteristics (Overall)

Conductor

AWG:

# Conductors	AWG	Stranding	Conductor Material
1	18	65x36	TC - Tinned Copper

Insulation

Insulation Material:

Insulation Material	Wall Thickness (in.)
PVC - Polyvinyl Chloride	.048

Overall Insulation

Overall Cabling

Overall Nominal Diameter:

0.144 in.

Applicable Specifications and Agency Compliance (Overall)

Applicable Standards & Environmental Programs

UL AWM Style:

1855

UL Rating:

5000 V, 80°C

EU CE Mark:

Yes

EU Directive 2000/53/EC (ELV):

Yes

EU Directive 2002/95/EC (RoHS):

Yes

EU RoHS Compliance Date (mm/dd/yyyy):

10/01/2005

EU Directive 2002/96/EC (WEEE):

Yes

EU Directive 2003/11/EC (BFR):

Yes

CA Prop 65 (CJ for Wire & Cable):

Yes

MII Order #39 (China RoHS):

Yes

Plenum/Non-Plenum

Plenum (Y/N):

Electrical Characteristics (Overall)

Suggested Working Voltage:

5000 V RMS
