商品編號: A-SOOW-90

SOOW 90ºC Synthetic Rubber Insulation Thermoset Jacket 輕便電源線 600V



For use as portable electrical power and portablecontrol cable. It can be used for ground test or motorleads. Also, it provides heavy-duty service for industrialtools, portable lights, battery chargers, and equipmentexposed to oils, solvents, flame and grease.

SOOW 90ºC
Synthetic Rubber Insulation
Thermoset Jacket
90°C, 600 Volts
　

APPLICATIONS:
For use as portable electrical power and portable
control cable. It can be used for ground test or motor
leads. Also, it provides heavy-duty service for industrial
tools, portable lights, battery chargers, and equipment
exposed to oils, solvents, flame and grease.
　

SPECIFICATIONS*:
1. CONDUCTOR: Bare, annealed copper per ASTM B-3. Flexible, bunch stranded per UL
62. A separator may be applied over the conductor.
2. INSULATION: Synthetic rubber per UL 62.
3. COLOR CODE: Per ICEA Method 1, Table K-1 except 3/C which is black, white, green.
4. ASSEMBLY: Insulated conductors are cabled with fillers as necessary to make round. A
separator is applied over the assembly.
5. OVERALL JACKET: Black, oil resistant thermoset compound per UL 62.
6. STANDARDS: Meets the UL 62 requirements for Type SOOW. Also meets
CSA requirements for Type SOOW. Accepted by MSHA and printed with the manufacturer’s
P number.
7. AMPACITY: Based on a 30°C ambient temperature per NEC Table 400-5(A). The values
are derated (where applicable) according to NEC Article 400-5.
8. TEMPERATURE: 90°C
9. VOLTAGE: 600 Volts
