Type no
HT-

Die
P/N

Specifications

Crimping cable size

5133A

3A

.256”/.068”/.213”
6.50/1.73/5.41mm

RG58, 59, 62

5133A4

3A4

.255”/.187”/.068”/.213”
6.48/4.75/1.73/5.41mm

RG58, 59, 62, 174

5133C

3C

.256”/.319”/.068/.213”
6.50/8.10/1.73/5.41mm

RG58, 59, 62, 6

5133C1

3C1

.068”/.216”/.324”/.360”
1.73/5.49/8.23/9.14mm

RG58, 59, 62, 6

5133C2

3C2

.68”/.262”/.324”/.360”
1.73/6.65/8.23/9.14mm

CATV”F” Connectors RG59, 6

5133D

3D

.213”/.256”/.068”/.324”
5.41/6.50/1.73/8.23mm

RG58, 59, 62, 6

5133D1

3D1

.068”/.178”/.324”
1.73/4.52/8.23mm

RG58, 6, 174

5133D2

3D2

.256”/.429”/.068”/.213”
6.50/10.90/1.73/5.41mm

RG58, 59, 62, 11, 8, 213

5133D3

3D3

.390”/.275”.065”
9.90/6.98/1.65mm

RG213, 6, 8, 59

5133F1

3F1

.042”/.068”.133”/.162”/1.95”
1.07/1.73/3.38/4.11/4.95mm

Fiber Optic SMA(Oval Type)

5133F2

3F2

.042”/.068”/.151”/.178”/.213”
1.07/1.73/3.84/4.52/5.41mm

Fiber Optic SMA, SMB Conn.
RG58, 174, Belden 8281

5133F3

3F3

.151”/.178”/.213”
3.84/4.52/5.41mm

RG58, 174, 179

5133F4

3F4

.151”/.178”/.134”/.139”/.190”
3.84/4.52/3.40/3.53/4.83mm

Fiber Optic ST, SC, LC connectors.

5133G

3G

.043”/.068”/.100”/.137”/.213””/.255”
1.09/1.73/2.54/3.48/5.41/6.48mm

RG58, 59, 62, 174
Fiber Optic

5133G1

3G1

.042”/.068”/.190”/.213”
1.07/1.73/4.83/5.41mm

RG58, Fiber Optic

5133G2

3G2

.235”/.128”/.065”/.042”
5.97/3.25/1.65/1.07mm

RG58, 174, 139, 185

5133G3

3G3

.042" / .068”/.255”/.324”
1.07/1.73/6.48/8.23mm

RG58, 59, 6

5133G4

3G4

.042”/.068”/.178”/.278”/.255”
1.07/1.73/4.52/7.06/6.48mm

RG59, 62, 174

5133H1

3H1

.255”/.320”/.350”
6.48/8.13/8.89mm

CATV Ｆ Connectors RG59, 6

5133H2

3H2

.320"/.210"/.185"
8.13/5.33/4.70mm

RG58, 6

5133I

3I

.254”/.211”/.093”/.067”/.315”
6.46/5.36/2.36/1.70/8.0mm

RG58, 59, 6, 174

5133J

3J

.042”/.068”/.078”/.128”/.151”/.178”
1.07/1.73/1.98/3.25/3.84/4.52mm

RG174, 179, Belden 8218 Fiber Optic

5133K

3K

.0100”/.128”/.429”
2.54/3.25/10.90mm

RG8, 11, 174, 179,, 213

LMR400

5133K2

3K2

.068”/.256”/.429”
1.73/6.50/10.90mm

RG8, 11, 59, 62

5133K3

3K3

.256”.068”/.295”
6.50/1.73/7.49mm

RG59, 6

5133K4

3K4

.100”/.128”/.190/.213”
2.54/3.25/4.83/5.41mm

RG58, 174, Fiber Optic

5133K5

3K5

.080”/.100”/.429”
2.03/2.54/10.90mm

RG11, 174, 213

5133K6

3K6

.429”/.075”/.075”
10.90/1.91/1.91mm

RG11, 213

5133M

3M

.288”/.268”/.305”
5.79/1.73/7.75mm

RG58, 59, 6, 62, 142

5133P1

3P1

.255”/.213”/.098”/.068”/.321”
6.48/5.41/2.49/ 1.73/8.15mm

RG58, 59, 62, 6

5133T1

3T1

.028”/.039”/.047”/.100”/.128”/.151”
0.71/0.99/1.19/2.54/3.25/3.84mm

RG174, 178, 179, 180, 187

5133V

3V

.043”/.069”/.100”/.128”/.151”/.213”
1.09/1.75/2.54/3.25/3.84/5.41mm

SMA, SMB, SMC, MCX

5133V1

3V1

.047”/.068”/.178”/.217”/.256”/.330”
1.19/1.73/4.52/5.51/6.50/8.38mm

RG59, 62 , 6 , 174, Fiber Optic

3Y

.044”/.057”/.068”/.220”/.213”
1.12/1.45/1.73/5.59/5.41mm

RG58

5133Y1

3Y1

.218"/.069”

5.54/1.75mm

RG58(Oval Type)

5133Y2

3Y2

.042”/.240"
1.07/6.10mm

Pin terminal, insulated or non-insulated ferrules
(Oval Type)

5132C

2C

AWG 20-18/16-14/12-10
DIN 0.5-1/1.5-2.5/4-6mm²

Non-insulated terminal or
open barrel terminal

5132CL

2CL

AWG 20-18/16-14/12-10
DIN 0.5-1/1.5-2.5/4-6mm²
(W/LOCATOR)

Non-insulated terminal or
open barrel terminal

5132C2

2C2

AWG 20-18/16-14
DIN 0.5-1/1.5-2.5mm²

Non-insulated terminal or
open barrel terminal

5132C3

2C3

AWG 24-30/18-22
DIN 0.25-0.05/1.0-0.5mm²

D-Sub terminal

5132C4

2C4

AWG 24-28/20-22
DIN 0.25-0.08/0.75-0.5mm²

D-Sub terminal

5132E

2E

AWG 22/20/18/16/14/12
DIN 0.5/0.75/1.0/1.5/2.5/4mm²

Pin terminal insulated
or non-insulated ferrules

5132E1

2E1

AWG 10/8/6
DIN 6/10/16 mm²

Pin terminal insulated or non-insulated ferrules

5132E2

2E2

AWG 22/20/18/16/14/12/10/8/6
DIN 0.5/0.75/1.0/1.5/2.5/4/6/10/16 mm²

Pin terminal insulated or non-insulated ferrules

5132E3

2E3

AWG 22/202/18/16/14/12/10
DIN 0.5/0.75/1.0/1.5/2.5/4/6 mm²

Pin terminal insulated or non-insulated ferrules

5132F

2F

AWG 22-18/16-14
DIN 0.5-1.0/1.5-2.5 mm²

Insulated flag terminal

5132F1

2F1

AWG 22-18/16-14
DIN 0.5-1.0/1.5-2.5 mm²

Non insulated flag terminal

5132H

2H

AWG 22-18/16-14/12-10
DIN 0.5-1.0/1.5-2.5/4-6 mm²

Insulated terminal

5132N

2N

AWG 20-18/16-14/12-10/8
DIN1.5/2.5/6/10 mm²
JIS 1.25/2.0/5.5/8 mm²

Non-insulated terminal

5132R

2R

AWG 22-18/16-14/12-10
JIS 1.25/2.0/5.5 mm²

Vinyl insulated w/o copper sleeve

5132U

2U

AWG 14-22
DIN 2.5-0.5 mm²

Non-insulated, open barrel & d-sub V.35 terminal

5132W

2W

AWG 22-18/16-14/12-10
DIN 0.5-1.0/1.5-2.5/4-6 mm²

Insulated terminal

5135C3

5C3

AWG 24/14
DIN 0.25/2.5 mm²

Din Spec. Open barrel terminal

5135D

5D

AWG 4/2/6
DIN 25/35/16 mm²

Pin terminal insulated or non-insulated ferrules

5135D1

5D1

AWG 4/1
DIN 25/50 mm²

Pin terminal insulated or non-insulated ferrules

5135D2

5D2

AWG 6/4/2
DIN 16/25/35 mm²

Pin terminal insulated or non-insulated ferrules

5135N1

5N1

AWG 8/6/4
DIN 10/16/25 mm²

Pin terminal insulated or non-insulated ferrules

5135N2

5N2

AWG 18-16/14/12-10/8
DIN 0.75-1.5/2.5/4-6/10 mm²

Non-insulated terminal

AWG 2.5/4/6
14/12/10
