    ALPHA-PIF2007/16 -70 to 200 度 MIL-I-3190E, NEMA VS-1, UL 1441 Fiberglass Silicone 套管
    看原圖
    		ALPHA-PIF2007-16



    商品編號: ALPHA-PIF2007-16

    ALPHA-PIF2007/16 -70 to 200 度 MIL-I-3190E, NEMA VS-1, UL 1441 Fiberglass Silicone 套管

    部件号 Material ID Expanded ID Temperature Colors Ratings
    PIF2007/16 Fiberglass Silicone 0.45 0.58 -70 to 200 Natural MIL-I-3190E, NEMA VS-1, UL 1441

    Alpha 拥有适合您用途的套管，非常适合柔性线束、防热和抗化学腐蚀和机械磨损。

    Part # Material ID Expanded ID Temperature Colors Ratings
    PIF2007/16 Fiberglass Silicone 0.45 0.58 -70 to 200 Natural MIL-I-3190E, NEMA VS-1, UL 1441
    PIF2008 Fiberglass Silicone 0.133 0.223 -70 to 200 Natural MIL-I-3190E, NEMA VS-1, UL 1441
    PIF2009 Fiberglass Silicone 0.118 0.208 -70 to 200 Natural MIL-I-3190E, NEMA VS-1, UL 1441
    PIF2400 Fiberglass 0.33 0.36 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2401 Fiberglass 0.294 0.324 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2401/2A Fiberglass 0.5 0.53 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24010 Fiberglass 0.106 0.136 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24011 Fiberglass 0.095 0.125 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24012 Fiberglass 0.085 0.115 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24014 Fiberglass 0.066 0.096 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24015 Fiberglass 0.059 0.089 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24016 Fiberglass 0.053 0.083 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24018 Fiberglass 0.042 0.072 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2401IN Fiberglass 1 1.03 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2402 Fiberglass 0.263 0.293 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF24020 Fiberglass 0.034 0.064 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2403 Fiberglass 0.234 0.264 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2403/4 Fiberglass 0.75 0.78 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2403/8 Fiberglass 0.375 0.405 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
    PIF2404 Fiberglass 0.208 0.238 -60 to 616 Natural NEMA VS-1, UL 1441, UL VW-1
