    ALPHA-FIT® Wire Management Acrylic-Coated Fiberglass Sleeving 壓克力 + 玻璃絲編織電線管理套管
    看原圖
    		ALPHA-AF-155-24



    商品編號: ALPHA-AF-155-24

    ALPHA-FIT® Wire Management Acrylic-Coated Fiberglass Sleeving 壓克力 + 玻璃絲編織電線管理套管


    FIT® Wire Management
    Acrylic-Coated Fiberglass Sleeving
    AF-155
    MIL-I-3190/3 Grade C1
    NEMA TF-1


    Operating Temperature
    • -30°C to +155°C
    Color
    • Natural
    Material
    • Acrylic-coated fiberglass braid Physical Properties
    • Elongation: 150% min.
    • Low-temperature (-10°C)
    flexing: no cracking
    Chemical Properties
    • Corrosive effect: none
    • Fungus resistance: no growth
    • Lead free
    Electrical Properties
    • Dielectric strength: 2500 V/mil (984 kV/cm)
    • Dielectric constant: 2.5
    • Volume resistivity: 1010 ohm-cm
    Availability
    See table
    Spools may contain multiple
    lengths

    Alpha套管产品尺寸齐全，具有抗燃烧、耐高温、防磨损和腐蚀，能满足您电线和电缆的布线要求。


    　 Part #

    　

    		 Material

    　

    		 ID

    　

    		 Wall Thickness　 Temperature Colors　
    AF-155-5 Fiberglass Acrylic 0.186 　 -30 to 155 Natural ASTM D 372, MIL-I-3190/3, NEMA TF-1, UL 1441, UL 746B, UL AF-155A Grade A
    AF-155-5/8 Fiberglass Acrylic 0.64 　 -30 to 155 Natural
    AF-155-6 Fiberglass Acrylic 0.166 　 -30 to 155 Natural
    AF-155-7 Fiberglass Acrylic 0.148 　 -30 to 155 Natural
    AF-155-7/16 Fiberglass Acrylic 0.45 　 -30 to 155 Natural
    AF-155-7/8 Fiberglass Acrylic 0.802 　 -30 to 155 Natural
    AF-155-8 Fiberglass Acrylic 0.133 　 -30 to 155 Natural
    AF-155-9 Fiberglass Acrylic 0.118 　 -30 to 155 Natural
