IDA-R-TYPE

商品編號: IDA-R-TYPE

Thermocouple Wire R-TYPE Seriors
補償導線

The wire can be used in various thermal places ranging from household appliances, lighting devices, industrial machines, to high-temperature furance.

R-TYPE Specifications

Wire Code	Specification	Dimension		Insulation Material	Conductor Material		Temperature Range	Mt/ Coils
Wire Code	Specification	ID (mm)	OD (mm) H x L	Insulation Material	(+)	(-)	Temperature Range	Mt/ Coils
PP-KC-22S	0.3/4 x 2 (22 AWG)	1.45	2.40 x 3.75	PVC	Copper	Ni-Copper	0 ~ 105C	200
PP-KC-20S	0.3/7 x 2 (20 AWG)	1.50	2.40 x 3.75	PVC	Copper	Ni-Copper	0 ~ 105C	200
PP-KC-16S	0.6/4 x 2 (16 AWG)	2.45	4.50 x 7.00	PVC	Copper	Ni-Copper	0 ~ 105C	200
PP-KC-14S	0.6/7 x 2 (14 AWG)	3.00	4.55 x 7.65	PVC	Copper	Ni-Copper	0 ~ 105C	200
PSP-KC-14S	0.6/7 x 2 (14 AWG)	3.00	4.90 x 7.80	PVC-SUS304	Copper	Ni-Copper	0 ~ 105C	200
SPP-KC-14S	0.6/7 x 2 (14 AWG)	3.00	5.80 x 8.20	PVC-SUS304	Copper	Ni-Copper	0 ~ 105C	200
GG-KX-28	0.3 x 2 (28 AWG)	0.75	1.40 x 2.50	Fiberglass	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
GG-KX-22	0.6 x 2 (22 AWG)	1.10	2.00 x 3.20	Fiberglass	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
GG-KC-22S	0.3/4 x 2 (22 AWG)	1.20	2.05 x 3.30	Fiberglass	Copper	Ni-Copper	0 ~ 200C	200
GG-KC-20S	0.3/7 x 2 (20 AWG)	1.50	2.00 x 3.50	Fiberglass	Copper	Ni-Copper	0 ~ 200C	200
GG-KC-16S	0.6/4 x 2 (16 AWG)	2.15	3.00 x 4.60	Fiberglass	Copper	Ni-Copper	0 ~ 200C	200
GG-KC-14S	0.6/7 x 2 (14 AWG)	2.40	3.30 x 5.20	Fiberglass	Copper	Ni-Copper	0 ~ 200C	200
SGG-KX-24	0.5 x 2 (24 AWG)	1.00	1.65 x 2.85	Fiberglass-SUS304	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
SGG-KX-22	0.6 x 2 (22 AWG)	1.10	1.75 x 2.95	Fiberglass-SUS305	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
SGG-KX-22S	0.3/4 x 2 (22 AWG)	1.20	1.80 x 3.05	Fiberglass-SUS306	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
HH-K-36	0.127 x 2 (36 AWG)	0.50	0.95 x 1.45	Silica Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 710C	200
HH-K-30	0.254 x 2 (30 AWG)	0.65	1.10 x 1.55	Silica Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 710C	200
HH-K-24	0.5 x 2 (24 AWG)	1.00	1.20 x 1.90	Silica Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 710C	200
HH-K-22	0.6 x 2 (22 AWG)	1.10	1.70 x 2.70	Silica Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 710C	200
HH-K-20	0.8 x 2 (20 AWG)	1.30	1.75 x 2.75	Silica Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 710C	200
CC-K-24	0.5 x 2 (24 AWG)	1.00	1.50 x 2.50	Ceramics Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 1200C	200
CC-K-20	0.8 x 2 (20 AWG)	1.30	1.75 x 2.75	Ceramics Fiber	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 1200C	200
TT-KX-36	0.127 x 2 (36 AWG)	0.29	0.42 x 0.75	Teflon	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
TT-KX-28	0.3 x 2 (28 AWG)	0.65	1.00 x 1.65	Teflon	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
TT-KX-24	0.5 x 2 (24 AWG)	0.85	1.20 x 1.85	Teflon	Chromel Ni-Cr	Alumel Ni-Al	1 ~ 200C	200
TT-KX-22	0.6 x 2 (22 AWG)	1.05	1.75 x 2.75	Teflon	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 200C	200
KK-K-24 KK-K-24S	0.5 x 2 (24 AWG) 0.2/7 x 2 (24 AWG)	1.00	1.20 x 2.20	KAPTON	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 400C	200
KK-K-20	0.8 x 2 (20 AWG)	1.30	2.00 x 3.00	KAPTON	Chromel Ni-Cr	Alumel Ni-Al	0 ~ 400C	200

TECHNICAL DATA
Material:PVC , Temp Range:-10 ~ 105C , Flame Retardant:Bad ,Friction Resist.:Good , Oil Resist.:Bad , Chemical Resist.:Fair , Waterproof:Good , Flexibility:Excellent
Material:EPR/HYP Rubber , Temp Range:-15 ~ 110C , Flame Retardant:Bad ,Friction Resist.:Good ,Oil Resist.:Good , Chemical Resist.:Good ,Waterproof:Good , Flexibility:Excellent
Material:Silicone , Temp Range:-60 ~ 200C , Flame Retardant:Good , Friction Resist.:Good , Oil Resist.:Excellent ,Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Excellent
Material:Silicone Waker 750 , Temp Range:-60~300C , Flame Retardant:Good , Friction Resist.:Good , Oil Resist.:Excellent , Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Excellent
Material:Teflon FEP , Temp Range:-100 ~ 200C , Flame Retardant:Excellent , Friction Resist.:Excellent , Oil Resist.:Excellent , Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Good
Material:Teflon PFA , Temp Range:-267 ~ 260C , Flame Retardant:Excellent , Friction Resist.:Excellent , Oil Resist.:Excellent , Chemical Resist.:Excellent , Waterproof:Excellent , Flexibility:Good
Material:KAPTON , Temp Range:-267 ~ 316C , Flame Retardant:Good , Friction Resist.:Good , Oil Resist.:Good , Chemical Resist.:Good , Waterproof:Fair , Flexibility:Fair
Material:Fiberglass , Temp Range:-100 ~ 500C , Flame Retardant:Excellent , Friction Resist.:Fair , Oil Resist.:Fair , Chemical Resist.:Excellent , Waterproof:Bad , Flexibility:Fair
Material:Fiberglass , Temp Range:-100 ~ 710C , Flame Retardant:Excellent , Friction Resist.:Fair , Oil Resist.:Fair , Chemical Resist.:Excellent , Waterproof:Bad , Flexibility:Fair
Material:Ceramic Fiber , Temp Range:-100 ~ 1200C , Flame Retardant:Excellent , Friction Resist.:Bad , Oil Resist.:Fair , Chemical Resist.:Excellent , Waterproof:Bad , Flexibility:Fair

ABBREVIATION GUIDE

Insulator		Conductor
English	Abbreviation	English	Abbreviation
PVC	P	Oxyen-Free Copper	OFC
EPR/HYP Rubber	Rb	Tinned Copper	TC
Silicone Rubber	Si	Nickel Plated Copper	NPC
Teflon FEP	T	Silver Plated Copper	SPC
Teflon PFA	T	Silver Plated	SPCCS
KAPTON	K	Copper Claded Steel
Fiberglass	G	Copper Claded Steel	CCS
Ceramic Fiber	C	Stainless Steel	SUS304
Aluminum+Ground	A	Pure Nickel	PN
