    首頁 > > ALPHA-Xtra-Guard® 5 Foil/Braid shielded Multipair 多對型鋁箔 銅網隔離超級耐候抗化學腐蝕电缆

    ALPHA 55121 Xtra-Guard 5 Maximum Temperature and Chemical resistant FEP (Awg24, 22, 20, 18) 300 V Foil/Braid Shielded, Multipair (–80°C to +200°C) 防腐，挑戰極限環境鐵氟龍耐高溫對型鋁箔銅網隔離電纜
    看原圖
    		ALPHA-55271

    商品編號: ALPHA-55271

    ALPHA 55272 Xtra-Guard 5 Maximum Temperature and Chemical resistant FEP (Awg24, 22, 20, 18) 300 V Foil/Braid Shielded, Multipair (–80°C to +200°C) 抗化學腐蝕,     食品醫療工業級, 鐵氟龍耐高溫對型鋁箔銅網隔離電纜

    Awg24:  Alpha55271, Alpha55272, Alpha55273, Alpha55276, Alpha55279, Alpha55279/12,

    Awg22:  Alpha55121, Alpha55122, Alpha55123, Alpha55126, Alpha55129, Alpha55129/12,

    Awg20:  Alpha55291, Alpha55292, Alpha55293, Alpha55296, Alpha55299, Alpha55299/12,

    Awg18: Alpha55131, Alpha55132, Alpha55133, Alpha55136, Alpha55139,


    Xtra-Guard® 5
    Maximum Temperature and Chemical Performance
    300 V Supra-Shield® Foil/Braid, Multipair
    UL AWM 20229
    UL CMP
    CSA CMP FT6


    Operating Temperature
    • –80°C to +200°C
    • –80°C to +150°C (AWM, CMP)
    Conductor Color Coding
    • Chart A (page 516)
    • Nine jacket tints (tan standard)
    • Custom colors available
    Materials
    • Stranded tinned copper conductors
    • FEP insulation
    • FEP jacket
    • Supra-Shield foil + braid shield: Aluminum/polyester/aluminum
         foil with 25% overlap min. Tinned copper drain wire sized
         the same as conductors Tinned copper braid, 70% coverage min.
    • Aramid fiber ripcord
    Availability
    Made to order
    1000 ft (305 m) minimum
    　
    FIT® Tubing Recommendations
    • FIT-650: Chemical/temperature
    resistant flexible fluoroelastomer
    • FIT-400: Temperature/chemical
    resistant FEP

    Xtra-Guard® 5 - Chemical resistant to withstand the most hazardous environments High TemperatureLow TemperatureUltraviolet LightOil, Chemicals, Solvents, FuelsAbrasionDirect BurialEMI Noise
    • Extreme-performance cable featuring Teflon FEP insulation and jacketing for reliable performance in temperatures from -80°C to +200°C
    • Suitable for use in Class 1 cleanrooms
    • Recognized by the FDA, when sterilized, for food- and medical-grade applications
    • Impervious to oils, solvents, chemicals, fuels, and acids
    • Provides exceptional protection against EMI when Supra-Shield is specified

    Xtra-Guard ® 5 – 防腐，适用于大多数极限环境 High TemperatureLow TemperatureUltraviolet LightOil, Chemicals, Solvents, FuelsAbrasionDirect BurialEMI Noise

    • 极限性能电缆，采用聚四氟乙烯绝缘和护套，在 -80°C 到 +200°C 温度下具有可靠的性能
    • 适合一级净化室使用
    • 经过美国食品及药物管理局认可，消毒后，可用于食品和医用级产品
    • 对油、溶剂、腐蚀和燃料具有防渗透性能
    • 与 Alpha 高性能屏蔽系统 Supra-Shield® 结合使用时，具有优异的抗电磁干扰/射频干扰性

      ----------------------------------------------------------------------------------------------------------------------------------------------------------
