    EUTECH- CON 110 CyberScan Conductivity Meter 攜帶型電導度計(RS232傳輸)
    看原圖
    		EUTECH-CON110


    商品編號: EUTECH-CON110

    EUTECH- CON 110 CyberScan Conductivity Meter 攜帶型電導度計(RS232傳輸)

    產品規格

    型號

    CON110

    測量範圍

    0~20.00、200.0、2000 μS/cm
    0~20.00、200.0 mS/cm、
    -10~110℃

    解析度

    0.01、0.1、1 μS/cm
    0.01、0.1 mS/cm

    精確度

    全刻度±1%

    校正方式

    1~5 點按鍵式自動校正

    溫度補償

    自動或手動，0~100℃

    尺寸重量

    180×90×40mm 290g

    輸出介面

    RS-232 可連接電腦或印表機

    產品特色

    　

    標準型機種，功能包括：電導度計、TDS (總固體溶解量) 及溫度計

    5 點自動校正：84、1413、12880、11180 μS/cm、及使用者自訂

    參考溫度：20及25℃ (可選擇)

    電極常數：K=0.1、1.0、10.0 (可選擇)

    大型 LCD 螢幕，同時顯示電導度及溫度

    資料儲存最多可達 100 筆

    可連續使用 200 小時，具省電功能設計，閒置 20 分鐘自動關機

    具自動檔位切換功能，操作使用十分簡便

    新加坡原裝進口 EUTECH

    Product Features

    :: Single & Multi-point Automatic or Manual Calibration for quick and easy calibration

    :: ±1% Full Scale Accuracy for precise and accurate measurements

    :: User Customizable Functions for options: Normalization Temperature, Temperature Coefficient, TDS (Total Dissolved Solids) factor, Cell constant and many more

    :: Auto-ranging Capability to detect the appropriate measurement range

    :: Stores/ Recalls up to 100 Data Sets with temperature readings

    :: RS232C Communication interface (for CON110) for downloading data to a computer or serial printer via a cable

    :: Complimentary Data Acquisition Software (for CON110) helps organize data to import into most popular spreadsheet programs for report generation

    :: Recall Electrode Characteristics and Previous Calibration Values for easy reference

    :: Self-Diagnostic with message codes for easy troubleshooting

    :: Stability Indicator prompts whenever reading stabilizes

    :: Auto-Power Off conserves battery power

    :: Large, Easy-to-Read Custom LCD Display with simultaneous readings provides optimum viewing with user-friendly icons

    :: Power with batteries or optional AC adapter for use in the field or at bench-top with built-in stand

    :: Rugged Carrying Case (Optional) provides handy on-site meter calibration and measurement
    CyberScan
    Carrying Kit
    RS232 Printer
    Buffer &
    Calibration Solutions
    (480 ml Bottles)

    Applications

    General: Monitor dissolved solids or conductivity levels quickly and easily in laboratories, field, schools and educational environments.

    Industrial: Use for testing pollution controls, water treatment, and testing for water hardness. Also useful for checking cooling towers, boiler water, font solutions in printing operations, brines, swimming pools, whirlpools and rise water.

    Agricultural: Use in aquariums, fish farms, hydroponics, and fertilizer/chemical concentrations.

    Specifications

    Product Specification

    		 Description
    Conductivity Range 0 to 19.99, 199.9, 1999 µS/cm; 19.99, 199.9 mS/cm
    TDS Range 0 to 9.99, 99.9, 999 ppm; 9.99, 99.9 ppt
    Resolution & Accuracy 0.05% Full Scale & ±1% Full Scale + 1 LSD
    Temperature Range -10.0 to 110.0 °C (14.0 to 230 °F) (Meter)
    Resolution & Accuracy 0.1 °C, 0.1°F (14 to 199.9) or 1.0°F (200 to 230)
    & ±0.5 °C (±0.9 °C)
    Calibration for Conductivity Automatic (single or multi-point up to 4 points) / Manual (up to 5 points)
    Calibration for TDS Manual (up to 5 points - 1 per range)
    No. of Calibration Points Up to 5 points (1 per range)
    Temperature Compensation Automatic / Manual (0 to 100 °C)
    Temperature Coefficient 0.0 to 10.0%/°C
    Normalization Temperature 20.0 or 25.0 °C
    TDS Factor 0.40 to 1.00 (selectable)
    Cell Constant 0.1, 1.0, 10.0 (selectable)
    Memory 100 data sets
    Special Functions Auto-ranging; Hold; Stability Indicator; Self-diagnostic;
    & Auto-Power Off after 20 minutes (selectable)
    Print Output Yes (RS232C)
    Power 4 AAA x 1.4V batteries or 9VDC power adapter

    Order Information

    Order No.

    		Item
    ECCON11003K CyberScan CON 110 Portable Conductivity/TDS/RS232 Meter with DAS, RS232C cable (ECCA01M09F09), Conductivity electrode (ECCONSEN91W), 1 electrode holder (15X000702) & carrying kit set EC-CONWPKIT
    ECCONWPKIT Conductivity/TDS Carrying Kit Set – Plastic Carrying Case comprises 1 x 1413 mS, 12.88 mS KCl, 3000 ppm 442 standard solutions (60 ml) and 1 x empty rinse water bottle (480 ml)
    ECCONSEN91W 2 Stainless Steel Rings Ultem-body Electrode with ATC, cell constant K=1.0, 16 x 110 mm, 6-pin connector, 1 m cable length (for CON 400/410 & CON 11/110)
