LHF-12D

LHF 12D / LHF-FR 12D (1/2")

• Low Attenuation The low attenuation of LHF coaxial cable series provides efficient transmission line for your RF system.
• Low VSWR The low VSWR of LHF coaxial cable series should guarantee your RF system without noise.
• Complete Protection The outer conductor of LHF coaxial cable series makes important contribution to minimize system interferences.
• Easy connecting Full line of high-quality connector and cable preparation tools to minimize installation time and cost

Construction
Inner Conductor Material / Construction : Copper-Clad Aluminum Wire
Inner Conductor Diameter (㎜) : 5.0

Dielectric Material / Construction : Foamed Polyethylene
DielectricDiameter (㎜): 12.5

Outer ConductorMaterial / Construction : Annularly Corrugated, Copper Tube
Outer Conductor Diameter (㎜) : 14.2

Jacket Diameter Standard Jacket (㎜) : 16.4
Jacket Diameter Halogen-Free / Flame-Retardant Jacket (㎜) : 16.4

LHF 12D (1/2″)
Min. Bending Radius (㎜)		125
Recommended Operating Temperature	Standard Jacket (ﾟC)	-40 ~ +80
	Halogen-Free / Flame-Retardant Jacket ©	-30 ~ +80
Nominal Weight	Standard Jacket (㎏/m	244
	Halogen-Free /Flame-Retardant Jacket (㎏/m)	262
Flat Plate Crush Resistance (㎏/㎜)		2
Max. Pulling Force (㎏)		113

Electrical Characteristics

		LHF 12D (1/2'')
DC Resistance Ω/1,000m (Ω/1,000ft)	Inner Conductor	1.6(0.5)
	Outer Conductor	1.9(0.6)
Insulation Resistance(MΩ•㎞)		10,000
Dielectric Strength(for 1 Min.)		DC 4000V
Velocity of Propagation(%)		89
Peak Power Rating(㎾)		40
Max. Operating Frequency(㎓)		8.8
Characteristic Impedance(Ω)		50
Return Loss(Typical Value) (㏈)		28
