MachFlex 375 YY Cables Unshielded PVC Control Cables

Applications
Designed for applications which are installed in occasional flexing and fixed locations. Cable
applications include precision control sensors, multi axis control machines, temperature
controllers, control panels, machine cutting tools, auxiliary equipment, motor speed control,
production machinery and many more.

General Reference Standards
• DIN VDE 0295, IEC 60228, BS6360
• DIN EN 50290-2-22, DIN VDE 0207-363-4-1
• IEC 60227-5, EN 50525-2-51
• DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2
• RoHS & REACH & CE Directives

Construction and Performance
1. Conductor Material Stranded bare copper (DIN VDE 0295 Class 5)
2. Insulation Material & Color PVC (polyvinyl chloride). A) Up to 5 cores: color-coded.
From 6 cores: Belden MachFlex Color code. B) G = with GN-YE protective
conductor; X = without protective conductor.
3. Braid Shield Material Tinned Copper Braid Shield
4. Jacket / Sheath Material PVC (polyvinyl chloride)
5. Flame Retardancy VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2
6. Voltage Rating (Uo/U) Up to 1.5 mm2: 300 / 500 V
From 2.5 mm2: 450 / 750 V
7. Oil Resistant DIN EN 50290-2-22 (TM54)
8. Temperature Range -5 °C TO +70 °C (Occasional movement)
-40 °C TO +80 °C (Fixed installation)
9. Bending Radius 10 x OD (Occasional movement)
4 x OD (Fixed installation)
10. Other Properties Good UV resistance, chemical resistance & flexibility
