    Teldor-90V1P12101 RS 485 120 Ω 1x2x24 AWG S/FTP PE Jacket
    看原圖
    		TELDOR-90V1P12101

    商品編號: Teldor-90V1P12101

    Teldor-90V1P12101 RS 485 120 Ω 1x2x24 AWG S/FTP PE Jacket


    RS 485 120 Ω 1x2x24 AWG S/FTP

    Part Number:
    90V1P12101
    　
    General Construction:
    120 Ohm cable for RS-485 applications.
    The cable contains one shielded with a mylar-aluminum tape and TC braid twisted pair and jacketed with a UV resistant black PE compound.
    Outer Jacket Material: PE
    Outer Diameter: 4.1 mm nom.
    Weight: 19 kg/km
    Design & Materials
    Conductor Material: Tinned Copper
    Conductor Size: 24 AWG
    Conductor Construction: 7x0.20 mm
    Insulation Material: PO
    Insulation O.D.: 1.4 mm nom.
    Conductor Color Code: White x Blue
    Overall Shield Design: 100% Coverage
    Overall Shield Material: Aluminum/Polyester Foil
    Overall Braid Shield: Yes
    Braid Coverage: 60 % nom.
    Outer Jacket Color: Black
    Marking: Per request
    Performance
    Impedance: 120 Ω
    Coupling Attenuation: Type II
    Max. DC Resistance : 92.0 Ω/km@20°C
    Attenuation: 2.6 @ 1 MHz, 5 @ 4 MHz, 7.9 @ 10 MHZ [dB/100m]
    Capacitance: 45 pF/m
    Velocity of Propagation: 75 % nom.
    Dielectric Strength: 700 V/minute
    Dielectric Strength to Shield: 700 V/minute
    Voltage Rating: 30 V
    Max. Operating Temperature: +70 °C
    Min. Operating Temperature: -40 °C
