ALPHA 470025YY
ALPHA-470025YY, Pro-Met 470 300/500V 2X0.5MM2 PVC/PVC MULTI CORE CONTROL CABLE VDE-REG 8770 柔性控制電纜
Pro-Met industrial cables are designed to perform better, providing consistent and reliable operation. The result is more uptime, fewer errors, and precise operation of equipment. Pro-Met’s round construction makes it easier to install, seal, and route
Pro-Met工業電纜的設計性能更高,可提供一致且可靠的運行。 結果是更長的正常運行時間,更少的錯誤以及設備的精確操作。 Pro-Met的圓形結構使安裝,密封和佈線更加容易
|
Diameters (mm) |
1) Component 1 |
2 X 1 COND |
|
a) Conductor |
0.50 (20/.177) mm2 Bare Copper |
0.91 |
b) Insulation |
0.400 mm Wall, Nom. PVC |
1.71+/- 0.08 |
(1) Print Color |
WHITE |
(2) Color Code |
Alpha Wire Color Code KZ |
Cond |
Color |
Cond |
Color |
Cond |
Color |
1 |
BLACK #1 |
2 |
BLACK #2 |
|
|
|
c) Cabling |
2 COND Cabled |
|
(1) Twists: |
14.7 Twists/meter (min) |
|
(2) Orientation: |
Components to be arranged from INSIDE LAYER to OUTSIDE LAYER |
|
d) Jacket |
0.65 mm Wall, Nom.,PVC |
4.76+/ 0.20 |
(1) Color(s) |
GREY |
2) Shield |
Tinned Copper BRAID Shield,80% Coverage, Min. |
|
3) Jacket |
0.80 mm Wall, Nom.,PVC |
7.10 (7.35 Max.) |
a) Color(s) |
Clear, Grey |
b) Print |
ALPHA WIRE-* P/N 470025CY
PRO-MET 300/500V 2X0.5MM2 PVC/PVC/TCB/PVC
MULTI CORE CONTROL CABLE ◁ VDE-REG 8770 ▷
CE ROHS DDDYANN XXXXXXX M
* = Factory Code |
Physical & Mechanical Properties |
1) Temperature Range |
-40 to 80°C(static), -30 to 70°C (dynamic) |
2) Bend Radius |
6X Cable Diameter(static), 20X Cable Diameter(dynamic) |
3) Sunlight Resistance |
Yes |
Electrical Properties |
(For Engineering purposes only) |
1) Voltage Rating |
300/500 VRMS |
2) Conductor DCR |
39 Ω/Km @20°C, Max. |
1) IEC |
|
|
a) Component 1 |
EN 60228 Conductors, Class 5 |
|
|
DIN VDE 0295 Class 5 |
|
2) Other |
IEC 60332-1 Flame Behavior |
|
|
DIN EN 50290-2-22 Oil Resistance |
|
|
UV Resistant |
|
3) CE: |
EU Low Voltage Directive 2014/35/EU |
keywords: ALPHA-470025YY, Pro-Met 470, VDE-REG 8770, 柔性控制電纜, VDE 0295, Class 5, VDE 0295, IEC 60332-1, Flame Behavior, DIN EN 50290-2-22, Oil Resistance, UV Resistant, |
|
