ALPHA-74004
ALPHA-74004, 26 AWG 4 Pair Shielded Zero Halogen Cat7 Flexible Ethernet Cable CAT7 柔性編織屏蔽 工業以太網路線
- AWG: 26
Temperature Range: -40 to 80
Jacket Material: ZH-PUR
# of Elements: 4
Insulation Material: FPE
Construction Type: PAIR
Application Ratings:CE, ROHS - RoHS Compliance, IEC EN 60811-2-1 , IEC 60754-2, ANSI 568-C2, EN 50173-1, ISO_IEC 11801, CSA FT2,
Construction
|
Diameters (In) |
1) Component 1 |
4 X 1 PAIR |
|
a) Conductor |
26 (7/34) AWG Bare Copper |
0.019 |
b) Insulation |
0.0118" Wall, Nom. Polyethylene, Foam-Skin |
0.042 |
(1) Color(s) |
|
|
Pair |
Color |
Pair |
Color |
Pair |
Color |
1 |
WHITE - BLUE |
3 |
WHITE - GREEN |
|
|
2 |
WHITE - ORANGE |
4 |
WHITE - BROWN |
|
|
|
c) Pair |
2/Cond Cabled Together |
|
(1) Twists: |
Staggered Lays |
|
Individually Applied: |
d) Shield: |
Alum/Mylar Tape, 25% Overlap, Min. |
|
(1) Foil Direction |
Foil Facing Out |
|
2) Cable Assembly |
4 Components Cabled |
|
a) Twists: |
4.4 Twists/foot (min) |
|
3) Shield |
Tinned Copper BRAID Shield,65% Coverage, Min. |
|
4) Jacket |
0.028" Wall, Nom., TPU (ZH) |
0.268 (0.283 Max.) |
a) Color(s) |
BLACK |
b) Print |
ALPHA WIRE-* P/N 74004 4PR 26 AWG
INDUSTRIAL ETHERNET SHIELDED
ANSI/TIA-568-C.2 CAT7 VERIFIED FT2
CE ROHS (SEQ FOOTAGE)
* = Factory Code |
