Belden-Speaker Cable “oxygen-free (OFC)” copper. 無氧銅 室內/室外,無鹵素,直埋,和商業及專業安裝高級喇叭線
Speaker Cables
Belden offers speaker cables for a wide range of applications, including plenum, indoor/outdoor, halogen-free, direct burial, and commercial and professional installations. All cables feature Electrolytic Tough Pitch (ETP) pure virgin copper construction (ASTM B3 and B8). We also offer Direct Burial speaker cable with ASTM B170 with ultra-high purity (99.995% pure), sometimes described as “oxygen-free (OFC)” copper.
We also offer larger gages up to 10 AWG in a UL-safety recognized construction, unique in the industry and also offer Class 2 or Class 3 wiring for high-power amplifiers that need this safety rating.
For some insight on proper speaker cable selection,
Speaker Cable
|
Speaker Cables |
FiberExpress Cables |
Part No |
Description |
5500UE |
2/C 22 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
8442 |
2/C 22 AWG 7 strand TC, PVC Insulation and Jacket, CMG, Heavy Duty |
9151 |
2/C 22 AWG 7 strand, open twist style, (1) tinned, (1) bare, VW-1 |
5400UE |
2/C 20 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
8205 |
2/C 20 AWG 7 strand TC, PVC Insulation and Jacket, CMG, Heavy Duty |
8649 |
2/C 20 AWG 7 strand, Zip style, (1) tinned, (1) bare, VW-1 |
5300UE |
2/C 18 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
8461 |
2/C 18 AWG 7 strand TC, PVC Insulation and Jacket, CMG, Heavy Duty |
8460 |
2/C 18 AWG 7 strand, open twist style, Black, White, VW-1 |
5200UE |
2/C 16 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
BE46382 |
2/C 16 AWG 30 strand (1.5 mm2) BC, PVC Insulation, PVC Jacket, round construction |
5200UP |
2/C 16 AWG 65 strand BC, TP Insulation, PVC Jacket, CM, Flex |
1307A |
2/C 16 AWG 65 strand OFHC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
8471 |
2/C 16 AWG 7 strand TC, PVC Insulation and Jacket, CMG, Heavy Duty |
8470 |
2/C 16 AWG 19 strand, open twist style, Black, White, VW-1 |
9497 |
2/C 16 AWG 19 strand, open twist style, Black, Orange, VW-1 |
5100UE |
2/C 14 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
5100UP |
2/C 14 AWG 42 strand BC, TP Insulation, PVC Jacket, CL3, Flex |
1309A |
2/C 14 AWG 105 strand OFC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
8473 |
2/C 14 AWG 7 strand TC, PVC Insulation and Jacket, CL3, Heavy Duty |
BE46381 |
2/C 13 AWG 50 strand (2.5 mm2) BC, PVC Insulation, PVC Jacket, round construction |
5000UE |
2/C 12 AWG 19 strand BC, PP Insulation, PVC Jacket, CMR |
5000UP |
2/C 12 AWG 65 strand, BC, TP Insulation, PVC Jacket, CL3, Flex |
1311A |
2/C 12 AWG 168 strand OFHC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
8477 |
2/C 12 AWG 7 strand TC, PVC Insulation and Jacket, CL3R, Heavy Duty |
BE46380 |
2/C 11 AWG 56 strand (4 mm2) BC, PVC Insulation, PVC Jacket, round construction |
5T00UP |
2/C 10 AWG 65 strand BC, TP Insulation, PVC Jacket, CL2 |
1313A |
2/C 10 AWG 259 strand OFHC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
|
|
2/C Speaker Cables - Halogen-free |
Part No |
Description |
46382NH |
2/C 16 AWG 30 strand (1.5 mm2) BC, PE Insulation, FRNC Jacket, round construction |
46381NH |
2/C 13 AWG 50 strand (2.5 mm2) BC, PE Insulation, FRNC Jacket, round construction |
46380NH |
2/C 11 AWG 56 strand (4 mm2) BC, PE Insulation, FRNC Jacket, round construction |
|
|
2/C Speaker Cables - Plenum |
Part No |
Description |
1863A |
2/C 18 AWG 19 strand BC, LS-PVC Insulation, open twist, CL2P |
6300UE |
2/C 18 AWG 7 strand BC, LS-PVC Insulation and Jacket, CMP |
1862A |
2/C 16 AWG 19 strand BC, LS-PVC Insulation, open twist, CL2P |
6200UE |
2/C 16 AWG 19 strand BC, LS-PVC Insulation and Jacket, CMP |
1861A |
2/C 14 AWG 19 strand BC, LS-PVC Insulation, open twist, CL2P |
6100UE |
2/C 14 AWG 19 strand BC, LS-PVC Insulation and Jacket, CL2P |
1860A |
2/C 14 AWG 19 strand BC, LS-PVC Insulation and Jacket, CL2P |
6000UE |
2/C 12 AWG 19 strand BC, LS-PVC Insulation and Jacket, CL2P |
6T00UP |
2/C 10 AWG 65 strand BC, LS-PVC Insulation and Jacket, CL2P |
|
|
4/C Speaker Cables - Non-Plenum |
Part No |
Description |
5202UE |
4/C 16 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
5202UP |
4/C 16 AWG 65 strand BC, TP Insulation, PVC Jacket, CM Flex |
1308A |
4/C 16 AWG 65 strand OFHC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
5102UE |
4/C 14 AWG 7 strand BC, PP Insulation, PVC Jacket, CMR |
5102UP |
4/C 14 AWG 42 strand BC, TP Insulation, PVC Jacket, CL3, Flex |
1310A |
4/C 14 AWG 105 strand OFHC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
5002UE |
4/C 12 AWG 19 strand BC, PP Insulation, PVC Jacket, CMR |
5202UP |
4/C 12 AWG 42 strand BC, TP Insulation, PVC Jacket, CL3, Flex |
Part No Here |
4/C 12 AWG 42 strand BC, TP Insulation, PVC Jacket, CL3, Flex |
1312A |
4/C 12 AWG 168 strand OFHC, Low Cap, Direct Burial, PO/PVC Jacket, CMR |
|
|
4/C Speaker Cables - Plenum |
Part No |
Description |
6302UE |
4/C 18 AWG 7 strand BC, LS-PVC Insulation and Jacket, CMP |
6202UE |
4/C 16 AWG 19 strand BC, LS-PVC Insulation and Jacket, CMP |
6102UE |
4/C 14 AWG 19 strand BC, LS-PVC Insulation and Jacket, CL2P |
6002UE |
4/C 12 AWG 19 strand BC, LS-PVC Insulation and Jacket, CL2P |
|
|
4/C Speaker Cables - Halogen-free |
Part No |
Description |
46379NH |
4/C 13 AWG 50 strand (2.5 mm_ ) BC, PE Insulation, FRNC Jacket, round construction |
|
|
8/C Speaker Cables - Non-Plenum |
Part No |
Description |
BE43907 |
8/C 13 AWG 300 strand (2.5 mm_ ) BC, PVC Insulation, PVC Jacket, round construction |
|
|
8/C Speaker Cables - Halogen-free |
Part No |
Description |
43907NH |
8/C 13 AWG 300 strand (2.5 mm_ ) BC, PE Insulation, FRNC Jacket, round construction |
|
|
BC = Bare Copper • CL2 = Class 2 • CL2P = Class 2 Plenum • CL3 = Class 3 • CL3R = Class 3 Riser • CM = Communications Rated • CMG = Communications General Purpose • CMP = Plenum Rated • CMR = Riser Rated • LS-PVC = Low Smoke PVC • OFHC = Oxygen-free High-conductivity • PO = Polyolefin • PO/PVC = Polyolefin insulation/PVC overall jacket • PP = Polypropylene VW1 = Vertical flame test-1 • TC = Tinned Copper • TP = Thermoplastic Belden offers several other cable types for all installations. |
|
|
企業的A / V系統的範圍可以從相對簡單到高度複雜的,綜合的寬帶多媒體網絡。只有百通可以提供廣泛的創新產品,以滿足這些不同的需求。
幾十年來,百通華晨已經佈線解決方案為專業廣播和娛樂行業的頭號選擇,其中包括美國全國廣播公司(NBC)和幾乎所有其他主要的廣播網絡,在系統停機時間根本不是一種選擇。在數字化升級,目前已接近完成,在美國,幾乎90%的所有使用的電纜是百通。
在電影業,以及其他文藝的應用,如盧卡斯電影公司,我們帶來同樣的無與倫比的一致性,質量,可靠性和性能。所有這些客戶遷移,一些比別人快,收斂統一的數據網絡音頻,視頻和控制應用。今天的企業市場必須了解和利用各種各樣的電線電纜產品,如下面的音頻,視頻和網絡佈線解決方案。
喇叭線
百通提供了廣泛的應用,包括全會,室內/室外,無鹵素,直埋,和商業及專業安裝音箱電纜。所有電纜採用電解韌(ETP)貞潔的童女銅建設(ASTM B3和B8)。我們還提供超高純度(純度99.995%),有時被描述為“無氧銅(OFC)”銅ASTM B170直埋揚聲器電纜。
我們還提供了較大的計至10 AWG在確認UL安全建設,在行業中獨樹一幟,還提供了2類或3類佈線需要這個安全評級的高功率放大器。
音頻電纜
Belden的音頻電纜廣泛的範圍從高性能,低電容模擬和數字音頻結構以獲得最佳的信號傳輸,電纜製造行業基本規範用於商業用途,短版印刷和非關鍵任務應用。百通率先推出了易帶箔粘結護套,便於安裝,數字電纜,阻燃電纜,2對版本現在提供這一功能。我們廣泛的產品線,精密同軸電纜數字音頻同軸(AES3-ID)應用的理想選擇,並提供大型場館的長期運行的應用程序的距離大幅延長。
我們還提供多對(多同軸)電纜捆綁,以簡化安裝。我們使這些超靈活的未分級的版本,CM,CMR(轉接卡額定),無鹵阻燃版本,為最苛刻的安裝要求。數字音頻蛇32對,52對模擬音頻蛇,多達12哄著捆綁的同軸電纜,將滿足每一位設計師和系統集成。
|
