Awg18: Alpha25522, Alpha25523, Alpha25524, Alpha25525, Alpha25527, Alpha25529, Alpha25539,

Awg16: Alpha25532, Alpha25533, Alpha25534, Alpha25535, Alpha25537, Alpha25539, Alpha25539/12,Alpha25539/15,Alpha25539/19,

Awg14: Alpha25542, Alpha25543, Alpha25544, Alpha25545, Alpha25547, Alpha25549, Alpha25549/12,

Xtra-Guard® 2 Oil and Abrasion Resistant
300 V Foil Shielded Multiconductor
UL AWM 20668 VW-1
CSA AWM I/II A/B FT1
Operating Temperature
• –30°C to +105°C
Conductor Color Coding
• Chart E (page 532)
• Nine jacket colors
(black standard)
• Custom colors available
Materials
• Stranded tinned copper conductors
• Premium PVC insulation
• Specially formulated
polyurethane jacket
• Nylon ripcord
• Specially formulated
polyurethane jacket
• UV resistant
• Supra-Shield foil + braid shield:
Aluminum/plyester/aluminum
foil shield, with 25% overlap min.
Tinned copper drain wire sized
the same as cable conductors
Tinned copper braid, 70%
coverage min. • Nylon ripcord
Availability
Made to order
1000 ft (305 m) minimum
　

Xtra-Guard ® 2 – 耐磨，可承受机械磨损

• 适合在磨损和机械损伤普遍的工业应用中使用
• 特制的坚韧聚氨酯护套，抗撕破性和耐磨性是普通聚氯乙烯的三倍
• 极高的抗切割和物理损坏性能
• 中至高度抗油、溶剂、化学品和燃料的性能
• 所有护套颜色都具有出色的紫外线照射稳定性
• 与 Alpha 高性能屏蔽系统 Supra-Shield® 结合使用时，具有优异的抗电磁干扰/射频干扰性能

Awg18: Alpha25522, Alpha25523, Alpha25524, Alpha25525, Alpha25527, Alpha25529, Alpha25539,

Awg16: Alpha25532, Alpha25533, Alpha25534, Alpha25535, Alpha25537, Alpha25539, Alpha25539/12,

Alpha25539/15, Alpha25539/19,

Awg14: Alpha25542, Alpha25543, Alpha25544, Alpha25545, Alpha25547, Alpha25549, Alpha25549/12,
